PARTS LIST

ITEM QTY REFERENCE
DC981A-3 Required Circuit Components
1 1 CPM
2 2 C1
3 2 C3, C4
4 1 D1
5 1 D2
6 1 J4
7 2 LED3, LED2
8 1 L1
9 1 RPM
10 1 R1
11 1 R2
12 1 R3
13 1 U1
Optional Circuit Components
1 1 C2
2 4 C5, C8, C11, C13
3 1 C6
4 2 C7, C12
5 2 C9, C10
6 2 D3, D5
7 1 D4
8 1 D6
9 2 D8, D7
10 2 J6, J5
11 1 LED1
12 2 R6, R8
13 1 R4
14 2 R5, R7
15 1 SW1
16 1 J3
17 1 U2
Hardware for Demo Board Only
1 5 E1, E2, E9, E10, E11
2 6 E3, E4, E5, E6, E7, E8
3 6 JP1, JP2, JP3, JP4, JP5, JP6
4 0 JP7
5 6 FOR JP1 TO JP6 (1 and 2)
6 2 J1, J2
7 4 MH1 TO MH4
PART DESCRIPTION
CAP, X5R, 1µF 16V, 10%, 0603
CAP, X7R, 0.1µF 16V, 10%, 0603
CAP, X7R 0.1µF 100V, 10%, 0603
DIODE, SWITCHING, SOT23
DIODE, 58V TVS, SMA-DIODE
JACK, POWER, RJ45-JK0-0144BNL
LED, GREEN, LED-ROHM, SML-010
IND, PWR, 10000µH, L-COIL-DS1608C
RES, CHIP 12.4k 1/16W 1%, 0805
RES, CHIP 2k 1/10W 5%, 0805
RES, CHIP 1k 1/16W 5%, 0603
RES, CHIP 10k 1/16W 5%, 0603
IC, LTC4263CS, SO14
CAP, X7R 1000PF 2kV, 1206
CAP, X7R, 0.1µF 16V, 10%, 0603
CAP, ELECT, 4.7µF 63V, C-PANA-EEVFK-C
CAP, X7R, 0.47µF 100V, 10%, 0805
CAP, X7R 0.1µF 100V, 10%, 0603
DIODE, SHOTTKY, PICO MINI, SOT563
DIODE, 58V TVS, SMA-DIODE
DIODE, RECTIFIER 3A, SMB-DIDOE
DIODE, 15V, ZENER, SOD323
CONN, RJ-45 RIGHT ANGLE, RJ45
LED, YELLOW, LED-ROHM, SML-010
RES, CHIP 1k 1/16W 5%, 0603
RES, CHIP 5.1k 1/16W 5%, 0603
RES, CHIP 510k 1/16W 5%, 0603
SWITCH, PUSH BUTTON
SOCKET, 1X6, 0.079", VERTICAL
IC, LTC4263CDE, DFN14DE
TP, TURRET, 0.094"
TP, TURRET, 0.064"
JMP, 1X3, 0.079"
JMP, 2X3, 0.079"
SHUNT, 0.079" CENTER
JACK, BANANA, KEY-575
STANDOFF, SNAP ON, 1/2"
DEMO MANUAL
DC981A/DC981B
MANUFACTURER/PART NUMBER
MURATA, GRM185R61C105KE44D
MURATA, GRM188R71C104KA01D
MURATA, GRM188R72A104KA35D
DIODES INC, BAS19-7-F
DIODES INC, SMAJ58A-13
PULSE, JK0-0144BNL
ROHM, SML-010FTT86
COILCRAFT, DS1608C-106MLC
VISHAY, CRCW080512K4FKEA
VISHAY, CRCW08052K00FKEA
YAGEO, RC0603FR-071KL
YAGEO, RC0603FR-0710KL
ANALOG DEVICES, LTC4263CS
MURATA, GR431BR7LA102KW01L
MURATA, GRM188R71C104KA01D
PANASONIC, EEE-FK1J4R7R
MURATA, GRM21BR72A474KA73L
MURATA, GRM188R72A104KA35D
CENTRAL SEMI, CMLSH05-4
DIODES INC, SMAJ58A-13
DIODES INC, S3BB-13-F
CENTRAL SEMI, CMDZ15L
STEWART CONN SYS, SS-6488-NF-K1
ROHM, SML-010YTT86
YAGEO, RC0603FR-071KL
AAC, CR16-512JM
VISHAY, CRCW0603510KJNEA
WÜRTH, 434 123 050 816
SAMTEC, SQT-106-01-LM-S-004
ANALOG DEVICES, LTC4263CS
MILL-MAX, 2501-2-00-80-00-00-07-0
MILL-MAX, 2308-2-00-80-00-00-07-0
SAMTEC, TMM-103-02-L-S
OPT
SAMTEC, 2SN-BK-G
KEYSTONE, 575-4
KEYSTONE, 8833
