Parts List - Analog Devices Linear Technology DC2603A-B Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Hardware: For Demo Board Only
1 16 E1, E3, E4, E5, E6, E7, E8, E9,
E10, E12, E13, E14, E15, E16,
E17, E18
2 1 JP1
3 3 JP2, JP3, JP4
4 1 JP5
5 5 XJP1, XJP2, XJP3, XJP4, XJP5
6 3 J1, J2, J3
7 2 J4, J5
8 4 J6, J7, J8, J9
9 8 J6, J7, J8, J9 (x2)
10 4 J6, J7, J8, J9
11 4 J6, J7, J8, J9
12 4 (STAND-OFF)
DEMO MANUAL DC2603A-B
PART DESCRIPTION
TEST POINT, TURRET, .094" MTG. HOLE
CONN., HDR, MALE, 2 × 4, 2mm, THT, STR
CONN., HDR, MALE, 1 × 3, 2mm, THT, STR
CONN., HDR, MALE, 2 × 3, 2mm, THT, STR
CONN., SHUNT, FEMALE, 2 POS, 2mm
CONN., RF , BNC, RCPT, THT, STR, 5-PIN
CONN., BANANA JACK, FEMALE, THT, NON-
INSULATED, SWAGE, 0.218"
STUD, FASTENER, #10-32
NUT, HEX, STEEL, ZINC PLATE,10-32
RING, LUG, CRIMP , #10, NON-INSULATED,
SOLDERLESS TERMINALS
WASHER, FLAT, STEEL, ZINC PLATE, OD: 0.436
[11.1]
STANDOFF , NYLON, SNAP-ON, 0.500"
MANUFACTURER/PART NUMBER
MILL-MAX, 2501-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000821121
WURTH ELEKTRONIK, 62000311121
WURTH ELEKTRONIK, 62000621121
WURTH ELEKTRONIK, 60800213421
AMPHENOL CONNEX 112404
KEYSTONE, 575-4
PennEngineering, KFH-032-10ET
KEYSTONE, 4705
KEYSTONE, 8205
KEYSTONE, 4703
KEYSTONE, 8833
dc2603abf
