DEMO MANUAL DC2737A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C1
2 1 C2
3 1 C6
4 1 C7
5 1 D1
6 1 D2
7 1 D3
8 1 D4
10 1 R1
11 1 R2
12 1 R3
13 1 T1
14 1 U1
Hardware: For Demo Board Only
9 5 E1, E2, E3, E4, E5
15 4 MH1, MH2, MH3, MH4
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP , X5R, 4.7µF, 50V, 10%, 0805
CAP , X5R, 100µF, 6.3V, 20%, 0805
CAP , ALUM, 10µF, 50V
CAP , X7R, 3300pF, 630V, 10%, 1206
SCHOTTKY DIODE, 30V, 2A, SOD123F
ZENER DIODE, 5.6V, SOD-523
DIODE, 1N4148WS SOD323
ZENER DIODE, 20V, 500mW, SOD123
RES, CHIP , 1M, 1/10W, 1% 0603
RES, CHIP , 210k, 1/10W, 1% 0603
RES, CHIP , 154k, 1/10W, 1% 0603
TRANSFORMER, 750313974
IC FLYBACK CONVERTER, SOT23-5
TESTPOINT, TURRET, 0.094" pbf
STAND-OFF , NYLON 0.25"
MANUFACTURER/PART NUMBER
MURATA, GRM21BR61H475KE51L
MURATA, GRM21BR60J107ME15L
PANASONIC, EFE-FTH100UAR
MURATA, GRM31BR72J332KW01L
NXP , PMEG3020EH,115
DIODES, BZT52C5V6T-7-F
DIODES, 1N4148WS-7-F
CENTRAL, CMHZ5250B
VISHAY, CRCW06031M00FKEC
VISHAY, CRCW0603210KFKEA
VISHAY, CRCW0603154KFKEA
WURTH, 750313974
LINEAR TECH, LT8301ES5#PBF
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 8831(SNAP ON)
dc2737af
