DEMO MANUAL DC2665B-C
QUICK START PROCEDURE
V
OUT
10mV/DIV
V = 20mV
OUT(PK-PK)
(a) 1V , 500kHz, Full Bandwidth at 500MHz
OUT
V
OUT
10mV/DIV
V = 18mV
OUT(PK-PK)
(c) 5V , 1.25MHz, Full Bandwidth at 500MHz
OUT
Figure 5. Tested V

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 3 C1, C6, C31
2 3 C2, C3, C38
3 1 C33
4 4 C5, C11, C12, C30
5 1 C7
6 1 C8
7 1 C10
8 1 C18
9 1 C29
6
dc2665bc F05a
1 s/DIV
dc2665bc F05c
1 s/DIV
AC Ripple at 12V
OUT
PART DESCRIPTION
CAP ., 2.2μF, X7R, 10V, 20%, 0603
CAP ., 22μF, X5R, 25V, 10%, 1206
CAP ., 1μF, X7R, 25V, 10%, 0603
CAP ., 220μF, X5R, 6.3V, 20%, 1206
CAP ., 0.1μF, X7R, 25V, 10%, 0603
CAP ., 100pF, X7R, 25V, 5%, 0603
CAP ., 220μF, ALUM HYB, 35V, 20%
CAP ., 1μF, X7R, 10V, 20%, 0603
CAP ., 0.022μF, X7R, 50V, 10%, 0603
V
OUT
10mV/DIV
V
OUT(PK-PK)
(b) 1V
V
OUT
10mV/DIV
V
OUT(PK-PK)
(d) 5V
, , I = 8A, V Ripple Is Tested Across C12
IN OUT OUT
1 s/DIV
= 6.8mV
, 500kHz, 20MHz Bandwidth
OUT
1 s/DIV
= 5.6mV
, 1.25MHz, 20MHz Bandwidth
OUT
MANUFACTURER/PART NUMBER
TDK, C1608X7R1A225M080AC
AVX, 12063D226KAT2A
TDK, C1608X7R1E105K080AB
MURATA, GRM31CR60J227ME11L
AVX, 06033C104KAT2A
AVX, 06033C101JAT2A
SUN ELECTRONIC, 35HVH220M
AVX, 0603ZC105MAT2A
KEMET, C0603C223K5RAC7867
dc2665bc F05b
dc2665bc F05d
