Parts List - Analog Devices LINEAR DC2702A-A Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 16 COUT1, COUT2, COUT3, COUT6,
COUT7, COUT8, COUT14, COUT15,
COUT16, COUT18, COUT19, COUT20,
COUT21, COUT22, COUT9, COUT10
2 1 CIN1
3 2 C2, C15
4 8 CIN2, CIN3, CIN4, CIN5, CIN6, CIN7,
CIN8, CIN9
5 3 C21, C22, C24
6 1 C23
7 1 C26
8 2 C27, C28
9 1 C33
10 26 E1, E2, E3, E4, E5, E6, E8, E9, E10,
E11, E12, E13, E14, E15, E16, E17,
E18, E19, E20, E21,E22, E23, E24,
E25, E26
11 1 J1
12 3 JP1, JP2
13 3 J2, J3, J4
14 6 J5, J6, J7, J8, J9, J10
15 12 J5, J6, J7, J8, J9, J10
16 6 J5, J6, J7, J8, J9, J10
17 6 J5, J6, J7, J8, J9, J10
18 1 J12
19 1 J11
20 4 MH1, MH2, MH3, MH4
21 2 Q1, Q2
22 1 Q3
23 6 R3,R25,R32,R69,R70,R93
24 8 R9,R29,R33,R63,R65,R66,R91,R92
DEMO MANUAL DC2702A-A
PART DESCRIPTION
CAP ., 330µF, X6S, 4V, 20%, 1210
CAP ., 180µF, ALUM. POLY., 25V, 20%, 8 × 12mm SMD,
E12
CAP ., 6800pF, X7R, 50V, 5%, 0603
CAP ., 22µF, X5R, 25V, 10%, 1210
CAP ., 1µF, X5R, 25V, 10%, 0603
CAP ., 1µF, X7R, 25V, 10%, 0805
CAP ., 0.1µF, X5R, 16V, 10%, 0603
CAP ., 0.01µF, X7R, 25V, 5%, 0603
CAP ., 22µF, X5R, 6.3V, 20%, 0603
TEST POINT, TURRET, 0.064", MTG. HOLE
CONN., SHROUDED HDR, MALE, 2 × 6, 2mm, VERT,
STR, THT
CONN., HDR,MALE, 1 × 3, 2mm, VERT, STR, THT
CONN., RF , BNC, RCPT JACK, 5-PIN, STR, THT, 50Ω
RING, LUG, CRIMP , #10, NON-INSULATED,
SOLDERLESS TERMINALS
NUT, HEX, STEEL, ZINC PLATE, 10-32
STUD, FASTENER, #10-32
WASHER, FLAT, STEEL, ZINC PLATE, OD: 0.436 [11.1] KEYSTONE, 4703
CONN., HDR, FEMALE, 2 × 7, 2mm, R/A THT
CONN., HDR, MALE, 2 × 7, 2mm, R/A THT
STANDOFF , NYLON, SNAP-ON, 0.50"
XSTR., MOSFET, N-CH, 40V, TO-252 (DPAK)
XSTR., MOSFET, P-CH, 20V, 5.9A, TO-236 (SOT23-3)
RES.,10 OHMS,1%,1/10W,0603
RES.,0 OHM,1/10W,0603,AEC-Q200
MANUFACTURER/PART NUMBER
TAIYO YUDEN, AMK325AC6337MM-P
PANASONIC, 25SVPF180M
AVX, 06035C682JAT2A
AVX, 12103D226KAT2A
MURATA, GRM32ER61E226KE15L
TAIYO YUDEN, TMK325BJ226KM-P
TAIYO YUDEN, TMK325BJ226KM-T
AVX, 06033D105KAT2A
NIC, NMC0603X5R105K25TRPF
AVX, 08053C105KAT2A
AVX, 0603YD104KAT2A
NIC, NMC0603X5R104K16TRPF
AVX, 06033C103JAT2A
MURATA, GRM188R60J226MEA0D
MILL-MAX, 2308-2-00-80-00-00-07-0
FCI, 98414-G06-12ULF
WURTH ELEKTRONIK, 62000311121
AMPHENOL RF , 112404
KEYSTONE, 8205
KEYSTONE, 4705
PENNENGINEERING, KFH-032-10ET
SULLINS CONNECTOR SOLUTIONS,
NPPN072FJFN-RC
MOLEX, 0877601416
MOLEX, 87760-1416
WURTH ELEKTRONIK, 702935000
VISHAY, SUD50N04-8M8P-4GE3
VISHAY, SI2365EDS-T1-GE3
"NIC, NRC06F10R0TRF
PANASONIC, ERJ3EKF10R0V
ROHM, MCR03EZPFX10R0
VISHAY, CRCW060310R0FKEA
YAGEO, RC0603FR-0710RL"
"NIC, NRC06ZOTRF
VISHAY, CRCW06030000Z0EA"
