DEMO MANUAL DC2910A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 2 C1, C2
2 2 C3, C4
3 1 C5
4 1 C6
5 1 C7
6 1 C8
7 1 R1
8 2 R2, R4
9 1 R3
10 2 R5, R11
11 2 R6, R7
12 1 R8
13 2 R9, R10
14 1 R12
15 1 U1
Additional Demo Board Circuit Components
1 0 C9-C12
2 0 C13-C16
Hardware: For Demo Board Only
1 11 E1-E11
2 2 JP2, JP3
3 4 MP1-MP4
4 3 XJP1-XJP3
6
PART DESCRIPTION
CAP ., 10uF , X5R, 16V, 10%, 0603
CAP ., 22uF , X6S, 6.3V, 20%, 0603
CAP ., 2.7pF, C0G, 50V, +/-0.25pF, 0402
CAP ., 1.2pF, C0G, 50V, +/-0.05pF, 0402
CAP ., 22uF , TANT. POSCAP , 6.3V, 20%, 2012 (0805)
S09, 150mOHM, TPU, NO SUBS. ALLOWED
CAP ., 220uF , TANT. POSCAP , 6.3V, 20%, 7343,
18mOHMS, TPE, NO SUBS. ALLOWED
RES., 140k OHMS, 1%, 1/16W, 0402, AEC-Q200
RES., 100k OHMS, 1%, 1/10W, 0402, AEC-Q200
RES., 261k OHMS, 1%, 1/16W, 0402
RES., 1M OHM, 5%, 1/16W, 0402
RES., 20 OHMS, 1%, 0.063W, 0402
RES., 10k OHMS, 1%, 1/10W, 0402
RES., 100k OHMS, 5%, 1/16W, 0402, AEC-Q200
RES., 10M OHMS, 1%, 1/16W, 0402
IC, Dual 2A Step-Down uMODULE REG, 24-PIN LGA ANALOG DEVICES, LTM4691EY#PBF
CAP ., OPTION, 0402
CAP ., OPTION, 0603
TEST POINT, TURRET, 0.094", MTG. HOLE
CONN., HDR, MALE, 1x3, 2mm, VERT, STR, THT
STANDOFF , NYLON, SNAP-ON, 0.375"
CONN., SHUNT, FEMALE, 2 POS, 2mm
MANUFACTURER/PART NUMBER
MURATA, GRM188R61C106KAALD
MURATA, GRM188C80J226ME15D
MURATA, GJM1555C1H2R7CB01D
MURATA, GJM1555C1H1R2WB01D
KEMET, T529P226M006AAE150
PANASONIC, 6TPE220MI
VISHAY, CRCW0402140KFKED
PANASONIC, ERJ2RKF1003X
VISHAY, CRCW0402261KFKED
VISHAY, CRCW04021M00JNED
VISHAY, CRCW040220R0FKED
PANASONIC, ERJ2RKF1002X
VISHAY, CRCW0402100KJNED
VISHAY, CRCW040210M0FKED
MILL-MAX, 2501-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000311121
KEYSTONE, 8832
WURTH ELEKTRONIK, 60800213421
Rev. 0
