Description Of The Inspection And Servicing Work; Testing The Residual Current Circuit Breaker; Cleaning The Enclosure; Checking For Damage From Vandalism - Bender iONiX Light 25 Wallbox Manual

Testing the surge protection device
PE conductor test
Checking the insulation resistance
Checking the filter for soiling and replacing it, if necessary
Visual inspection: For defects on the cable and terminals, blackened areas,
humidity, animal damage
m = monthly, 6 m = half-yearly, y = yearly
9.3

Description of the inspection and servicing work

DANGER
Danger to life
Before starting work, switch off the DC Wallbox.
9.3.1

Testing the residual current circuit breaker

Proper functioning of the residual current circuit breaker is of utmost importance. It is the last resort for
safeguarding human life and is only used if a series of errors has previously caused accessible parts of the DC
Wallbox to be under voltage.
The residual current circuit breaker shall be located in the wiring box or in the distribution board of the mains
supply. No residual current circuit breaker is integrated in the DC Wallbox.
When operating the DC Wallbox for the first time in previously unknown environments, a monthly test interval
is recommended. Based on documented experience, this interval can be extended to up to 12 months if no
known malfunctions have previously occurred in devices of the same age and under similar use conditions.
For a positive test, the residual current circuit breaker must switch off. Alternatively, an RCD tester can be used.
This tester makes contact with the upper contacts of the residual current circuit breaker.
9.3.2

Cleaning the enclosure

The outer enclosure should be cleaned with a hand brush or vacuum cleaner. Coarser soiling can be removed
with a damp cloth if necessary with the aid of normal household cleaner.
CAUTION
High pressure can cause damage.
Do not use air or water pressure cleaners inside the enclosure.
9.3.3

Checking for damage from vandalism

Depending on the operating environment, regular inspections at least once a year are recommended.
Work to be executed
Caution current!
Device damage!
iONiX 25_DC-Wallbox_D00461_01_M_XXEN/01.2024
iONiX Light 25 Wallbox
iONiX Medium 25 Wallbox
iONiX Supreme 25 Wallbox
m 6 m
x
y
x
x
x
x
