CAUTION
The installation location must be chosen such that no direct lightning strike can occur.
The enclosure is attached to a wall when open. The DC Wallbox is hung on the wall via the mounting rail and
screwed on at the bottom.
ADVICE
For a concrete wall, use the screws supplied. If the wall is not a concrete wall, the appropriate screws
must be used.
To guarantee safe mounting and to avoid concentrated loads on the wall, the specified five attachment points
(see chapter "Mounting", page 21 Mounting dimensions) must be used.
Exercise caution to avoid damage to the device!
The DC Wallbox must be lifted onto the wall
using a lifting table!
