Dimensions and mounting
Mounting, top
View of the mounting rail
Mounting, bottom
View with the door of the DC Wallbox open
24
iONiX 25_DC-Wallbox_D00461_01_M_XXEN/01.2024
Mounting rail for attachment to the wall
1: Retaining lug, top (outside)
2: Spacer for attachment points, bottom (outside)
1: Attachment points, bottom (inside)
