Testing
Checking the public key
ADVICE
Optionally the public key can be found directly at the front of the energy meter. It is visible when the
wallbox door is opened.
Note: When the door is opened, the operator securing mechanism is destroyed and must be
replaced.
9.1.3

Calibration and adjustment procedure

Calibration and adjustment as part of the checking of devices in operation are not necessary.
9.2

Maintenance and servicing

Every operator is advised to log all inspection and servicing work in a servicing record book.
Servicing essentially includes the following:
• Testing the residual current circuit breaker in the wiring box or distribution box of the mains supply
• Cleaning the enclosure
• Checking for damage from vandalism
• Checking the CCS2 plug face
• Check for sufficient holding force of the charge plug in its socket at the DC Wallbox
• Testing the filters
• Testing the surge protection device
• Checking the function of the residual direct current sensor
• Testing the PE conductor of the mains supply for continuity
The outer enclosure of the DC Wallbox is secured with the operator securing mechanism and a lock.
The following equipment or materials are required for inspection and servicing work: key, operator
securing mechanism, vehicle or vehicle simulator, circuit breaker tester.
After the work, a new operator securing mechanism must be applied!
9.2.1

Inspection and servicing plan

Periodic verification shall be performed in accordance with DIN IEC 60364-6:2016. The test results shall be
stored for a trend analysis.
The following intervals are recommendations. Deliberate deviations from them that are based on past
experience are permissible and shall be documented.
Testing the residual current circuit breaker
Cleaning the DC Wallbox from the outside and inside
Checking for damage from vandalism
Checking for free movement of the charging socket lock/functional test
Checking for sufficient holding force of the charge plug in its socket
48 iONiX 25_DC-Wallbox_D00461_01_M_XXEN/01.2024
Work to be executed m 6 m
x
(x) (x)
y
x
x
x
x
