Initial commissioning

6 Initial commissioning
ADVICE
If invoicing is carried out in accordance with calibration law, the DC Wallbox must be approved by
the responsible calibration authority or by a repairer if components relevant under calibration law are
modified (e.g. CCS2 charging cable, DC energy meter or DC charge controller).
When establishing the electrical connection, ensure that the back-up circuit breaker of the low-voltage
connection is "OFF".
ADVICE
Before establishing the electrical connection, ensure that the device is dry (e.g. no condensation). If
necessary, the device can be dried using an external hot air blower (T
ADVICE
The conditions in which condensation occurs in the device are detected by the control electronics. As
a countermeasure, part of the PU is activated for drying.
After establishing the electrical connection, ensure that no vehicle is connected to the charging cable when
the system is first switched on via the back-up circuit breaker.
After the system has been switched on for the first time, system parameters can be configured if necessary.
Configuration is carried out via a standard PC or laptop with Linux, Mac or Windows operating system.
Access to configuration interface
The computer can be connected to the DC Wallbox via the USB interface of the DC charge controller (terminal
O, micro USB, see chapter "Connection of components", page 28 Description of the DCC613 terminals) or
via the Ethernet interface (no. 19 (XG14, see chapter "Device view", page 13)) of the DC charge controller.
During initial installation, the connection to the configuration interface must be established by browser via
the USB interface of the DC charge controller by visiting the address http://192.168.123.123. The configuration
interface provides online help regarding the setting options for the individual parameters.
You must read and understand the explanations on the configuration interface BEFORE modifying a
parameter.
ADVICE
After initial commissioning, carry out an initial verification in accordance with DIN VDE 0100-600.
After this, the DC Wallbox should only be switched off for servicing purposes.
32 iONiX 25_DC-Wallbox_D00461_01_M_XXEN/01.2024
=50°).
max
