28
TB1
Voltage supply 230 V AC / 12 V DC for the charging electronics: Mean Well HDR-100-12
29
-
Air baffle
30
-
Locking mechanism
Via the circuit breaker (25) the DC Wallbox can be switched on and off.
3.2.2

Designations

The DC Wallbox variants that are in compliance with the applicable legal regulations on calibration are listed in
chapter "Ordering information", page 55.
Name plate
Located on the enclosure above the
socket
View from the right
Description
Depiction
iONiX 25_DC-Wallbox_D00461_01_M_XXEN/01.2024
iONiX Light 25 Wallbox
iONiX Medium 25 Wallbox
iONiX Supreme 25 Wallbox
