Design and operation

3 Design and operation
ADVICE
Some of the functions described in the following chapters depend on the selected variant (see
chapter "Ordering information", page 55) and are not available in all DC wallboxes.
3.1

Intended use

The DC Wallbox is intended for DC charging of electric vehicles in charging mode 4, in accordance with IEC
61851-1 and IEC 61851-23. It has been designed for use outdoors and in enclosed rooms, provided that the
occurrence of direct lightning current can be excluded. Its design for use in continuous operation and its
optionally available compliance with calibration regulations make it suitable for both use in private and public
spaces.
In accordance with its intended use, operation requires compliance with the conditions of the connected
network (grid code) in accordance with chapter "Network connection", page 26. When operating in
enclosed spaces, fresh air supply must be ensured. Only vehicles with a CCS2 charging connection that
support the standards in chapter "Standards and approvals", page 54, may be charged. The use of
extension cables or plug adaptors is expressly not permitted and, in accordance with the applicable standards,
not allowed.
Any other use than that described in this manual is regarded as improper.
3.1.1

Device-specific safety instructions

DANGER
When the DC Wallbox is connected to the power supply, a DC voltage of up to 1000 V may be present at
the DC output of the PU.
When no maintenance work is carried out by an electrically skilled person, the DC Wallbox must
always be locked and secured against opening.
After charging has completed (plug has been disconnected from the vehicle), wait until the minimum
discharging time has passed before opening the wallbox. After opening the DC Wallbox, verify that
the AC and the DC circuits are de-energised.
WARNING
Due to possible high temperatures inside the DC Wallbox, there is the danger of burns when the door is
opened.
Before opening the door, check the temperature of the DC Wallbox and, if necessary, take into
account that the DC Wallbox needs to cool down.
12 iONiX 25_DC-Wallbox_D00461_01_M_XXEN/01.2024
Electric shock!
Heat generation!
