Connection

5
Connection
5.1

Network connection

DANGER
Danger to life
The electrical supply line, which is supplied from the sub-distribution, must be de-energised during
the entire mechanical mounting process and electrical installation. The galvanic connection to the
low-voltage network may only be established after the mounting process and electrical installation
have been completed.
All prescribed safety regulations, the technical connection conditions (TAB) of the responsible power
supply company (PSC) and the regulations of the German Association for Electrical, Electronic & Information
Technologies VDE must be observed during installation and operation of the DC Wallbox.
ADVICE
Only installation companies registered in the installation directory of the respective system operator
are allowed to connect the DC Wallbox to the power supply (Section 13 of Germany's Low-Voltage
Connection Ordinance – NAV).
Only trained personnel are authorised to commission the device. To be able to carry out work on
the IONIX Wallbox, the installer needs to obtain the certification issued by the Bender Academy or a
system partner.
Installation guidelines of the respective grid operator must be observed.
To protect against overvoltage, the DC Wallbox is equipped with a type 2 surge protection device in the power
supply and in the information technology system. It is therefore suitable for use in lightning protection zone
(LPZ) 0B (see DIN VDE 0100-443, DIN EN 62305), provided the necessary protective measures are taken.
Before carrying out installation, servicing or commissioning work on the DC Wallbox, the following steps must
be taken:
• Disconnect the power supply line from the power supply
• Secure against reconnection
• Verify that the device is de-energised
ADVICE
Never open the enclosure when the device is live
In particular, the following protective measures must be implemented:
• Residual current circuit breaker (RCD type A)
• Surge protection device, type 1 (SPD type 1, normally part of the building power supply)
• ≤ 50A circuit breaker
• Earth terminal at least 10 mm² Cu
Connection is only allowed on the following network types:
• TN-S
• TN-C-S
• TT
26
iONiX 25_DC-Wallbox_D00461_01_M_XXEN/01.2024
Electric shock
