Design and operation
Position of the securing mechanism
Bottom view
with the door closed
*
Depending on the operator, the operator securing mechanism may differ from the one depicted here.
3.3
System overview
Legend
A1
A2
B
C
D
E
F
G
H
I
18
iONiX 25_DC-Wallbox_D00461_01_M_XXEN/01.2024
Public power-supply grid
Local communication network
AC supply
Ambient lighting
Status indicator
Connection indicator
CCS2 vehicle inlet
USB (service)
Display
GSM / LTE (optional)
Depiction*
Dimensions 60 x 20 mm
Description
HV supply (L1, L2, L3, N)
Optical interfaces
HV supply (DC)
Communication (PLC, CP, PP)
