Operation - Bender iONiX Light 25 Wallbox Manual

Operation

7 Operation
The DC Wallbox can be used intuitively by users without special training. Additional markings or drawings
can be attached to make first-time use easier.
Depiction of operating elements (exterior view from the front)
Legend
Designation
1 Light sensor
2 Display
3 RFID card reader
4 Meter window
34 iONiX 25_DC-Wallbox_D00461_01_M_XXEN/01.2024
The light sensor is used to adjust the brightness of the display and of the
status indicator to the brightness of the surroundings.
The touchscreen visualises the interaction between the user and the control
of the DC Wallbox. It enables the user to select the desired function and to
start or stop the charging process.
The RFID card reader permits authentication.
The built-in DC energy meter is visible through the meter window. It allows
the end user to check the amount of energy supplied to the vehicle.
Description
