7.3

Modes of operation

The DC Wallbox enables two modes of operation:
• Authorisation before the vehicle is plugged in
• Authorisation after the vehicle is plugged in
Authorisation can be carried out in different ways:
• via RFID MiFare card
- the card's UID is used for authorisation
• via remote access from the backend (APP)
7.4

Charging

The left or the right column of the following overview applies, dependent on whether the charge plug was
plugged into the vehicle before or after the display was touched. The middle column applies to both modes of
operation.
The authorisation status is indicated both on the ALM and by the LEDs on the RFID display field. Both modes of
operation are described in the following next to the depicted display screen.
Notes
While authorisation is in progress, the LEDs at the top of the ALM light up blue and the LEDs of the RFID
card reader white as a circle.
The display screen returns to "Available" if
• authorisation was not successful. All 3 LEDs of the DC Wallbox flash briefly to signal the error.
• the vehicle was not plugged in within 45 seconds.
