Bender iONiX Light 25 Wallbox Manual page 31

PU
HMI180
View: front
View: front
Terminal
T
U
V
W
Terminal
X1
X2
X3
X4
X5
X6
X7
X10
X11
X13
KK
iONiX 25_DC-Wallbox_D00461_01_M_XXEN/01.2024
iONiX Light 25 Wallbox
iONiX Medium 25 Wallbox
iONiX Supreme 25 Wallbox
Designation
X10 – AC input
X12 – 24 V supply
X20 – DC output
X30 - 2x CAN interface, control contact
for active discharging
Designation
Display and LED backlight interface
USB touch control interface, display
(10 pole)
Ambient lighting, temperature sensor
and operating status indicator (8 pole)
LED output (6 pole)
Supply and plug lighting (8 pole)
LTE/WiFi antenna input
LTE antenna output
Ethernet interface (RJ45)
USB type B interface for charge
controller
Ethernet interface for service interface
(RJ45)
Heat sink
