Operation
7.2
Status indications on the RFID display field
Similar as depicted
LED
lights up in parallel
1
to 3
lights continuously
2
slowly flashing
lights continuously
slowly flashing
3
quickly flashing
slowly flashing
4
quickly flashing
2, 3, 4*
quickly flashing
*
For error-correction measures, refer to the manual of the DC charge controller.
36
iONiX 25_DC-Wallbox_D00461_01_M_XXEN/01.2024
• Authorisation process is ongoing
• The current authorisation is signalled by circular light patterns
• Charging system is available
• No vehicle connected
• Charging system is available
• Vehicle connected
• Charging system is reserved
• No vehicle connected
• Charging system is reserved
• Vehicle connected
• Exchange of data from the backend
• Waiting for authorisation
• Charging is authorised
• Vehicle is being charged
• Charging system is authorised
• Vehicle not yet connected or separated from the charging system
• Authorisation declined
• Error in the charging system
• Backend not available
