Gema MagicCompact BA04 Operating Instructions And Spare Parts List page 58

MagicCompact BA04 - fan control unit
Fan control unit - complete
4 Plastic tube - Ø 6/4 mm
6 Locknut - M20x1.5 mm
7 Locknut - M40x1.5 mm
8 Cable connection - M20/1/8-15 mm
9 Cable connection - M40/1/28.5-33 mm
10 Elbow joint - 6-1/8"-6 mm
11 Elbow joint - 1/8"a-Ø 6 mm
12 Adjusting elbow - Ø 6/8 mm
13 Lead-through connection - Ø 8/8 mm
14 Switch - 0,75-5,6 kPa
Switch - 1.25-11.0 kPa
15 Pressure gauge - 0-2.5 kPa, differential pressure
Pressure gauge - 0-5.0 kPa, differential pressure
16 Pressure gauge - 0-5.0 kPa, differential pressure
Pressure gauge - 0-8.0 kPa, differential pressure
20 Main switch - see corresponding wiring diagram
21 Connecting socket/plug - see corresponding wiring diagram
# Wearing part
56 • Spare parts list
V 06/13
Order Motor
number performance (kW)
1004 358 5.5
1004 359 7.5
1004 937 11
1004 360 11
1004 938 15
1004 361 15
1002 178 22
1002 205 22
1002 179 30
1002 174 30
1002 180 37
1002 175 37
1002 176 45
1002 177 55
Pressure gauge (kPa)
Filter Fan
(pos. 15) (pos. 16)
5.0 8.0
5.0 8.0
2.5 5.0
5.0 8.0
2.5 5.0
5.0 8.0
2.5 5.0
5.0 8.0
2.5 5.0
5.0 8.0
2.5 5.0
5.0 8.0
5.0 8.0
5.0 8.0
MagicCompact BA04
see table
103 144#
266 035
265 357
266 019
265 349
245 950
254 061
237 990
253 880
243 744
243 752
243 760
243 779
243 779
251 844
