Gema MagicCompact BA04 Operating Instructions And Spare Parts List page 54

MagicCompact BA04 - gun blow off equipment
Gun blow off unit, complete (pos. 1-4)
1
Nozzle holder, complete
2 Nozzle
3 T-piece - 3/8i-3/8a-3/8i
4 Allen grub screw - M6x16 mm
5 Hose connector - Ø 17 mm, 3/8"a
6 Hose clamp - Ø 17-25 mm
7 Compressed air hose - Ø 16.4/26.6 mm, black
8 Solenoid valve
9 Valve coil - 24 VDC (for pos. 10)
10 Valve cable - 3 pins, M12, for pos. 11
11 Grounding cable - complete
* Please indicate length
# Wearing part
52 • Spare parts list
V 06/13
1010 015
1010 013
1010 014
223 034
214 850
233 077
223 085
105 155*
1005 592
1005 119
1008 244
1006 077
MagicCompact BA04
