Troubleshooting

General information
Problem fixing
MagicCompact BA04
V 06/13
Warning:
Faults may be fixed by trained personnel only!
Malfunctions, which arise during operation, are registered together with
emergency stops in a list with date and time indications. An error
message is displayed on the operating unit of the control unit.
If a fault arises, the plant is not stopped. However, if an emergency stop
arises, the whole plant (or units) is switched off and the emergency stop
mask is displayed on the operating unit.
The alarm horn sounds at the same time with every message
(malfunction or emergency stop).
Problem/error/malfunction
Alarm has been released:
Message too little powder bright
(dark)
Display flashes in the powder center
Powder shortage in the powder
container
Alarm has been released:
Message EMERGENCY STOP
protective switch
Motor malfunction exhaust air fan,
corresponding motor protection
switch has reacted
Procedures/remedy
Acknowledge error, fill in fresh
powder
Switch off the alarm, fill in fresh
powder
Let the motor cool down, switch on
the corresponding motor protection
switch again (see wiring diagram),
see also the "Troubleshooting"
section in the After Filter operating
manual. In the case of repeated
alarm, contact your Gema service
center
Troubleshooting • 43
