Design and function

Field of application
Function description
MagicCompact BA04
V 06/13
MagicCompact coating booths are used for the electrostatic powder
coating of all types of workpieces in large batches with frequent color
changes. As part of the process controlled coating plant, they are laid out
for fully automatic operation.
The most important characteristics of the MagicCompact BA04 coating
booths are:
Superstructure and booth basement in plastic material
-
Low booth basement height
-
Permanent powder suction from the entire booth floor
-
(suction openings integrated into the booth floor)
Automatic floor cleaning (no powder accumulation)
-
Integrated exhaust air main collector
-
Fast color change by one person
-
The guns are arranged vertically
-
The principle of function is determined by the requirements placed on the
booth, which are:
The protection of the coating process from external
-
influences, combined with keeping the area around the booth
clean
The powder recovery
-
The avoidance of an explosive powder/air mixture inside the
-
booth
An efficient exhaust air system is used to keep the area around the booth
clean and to prevent explosive powder/air mixtures.
The fan in the After Filter extracts the air from the inside of the booth
through the cyclone and afterwards through the filter elements. The air
stream created thereby, flowing from the outside to the inside of the
booth, prevents powder escaping to the environment of the booth, so that
keeping the area around the booth clean is guaranteed. The
maintenance of the air flow prevents as well the creation of dangerous
powder/air mixtures.
