Operation

Before switching on the booth
Switch on the booth
Switching off the booth
MagicCompact BA04
V 06/13
Strictly observe the safety regulations (see also "General
-
safety regulations")
Check the grounding of the booth and the other plant units
-
and ensure it, if necessary
If necessary, carry out a function check before starting work
-
After long stops/standstills
1. Fill in or refill powder
2. Check the tight seating of the filter cartridges
3. Place the refuse container under the After Filter
1. Open the compressed air supply and set the input pressure
for the After Filter
2. Turn on the main switch (the main switch is located on the
control cabinet)
3. Turn the key switch, the control unit is activated, the
operating unit is activated and the key switch returns to its
starting position.
4. Start the system, the main menu appears on the operating
unit, the fan in the powder center runs up
5. Activate the powder center (see therefore the corresponding
user manual)
1. Quit the automatic operation mode
2. Switch off the gun control units and all additional plant units
3. Switch off the system in the main menu
4. Switch off the powder center
5. Switch off the main switch
Operation • 29
