Technical data

MagicCompact BA04 powder coating booth
MagicCompact BA04
V 06/13
Electrical data
MagicCompact BA04
Input voltage
Pneumatic data
MagicCompact BA04
Input pressure
Air entry speed
Rinsing air in filter housing
Water vapor content of compressed air
Oil content of compressed air
Compressed air consumption
MagicCompact BA04
Rinsing air in filter housing
Dimensions
MagicCompact BA04
Booth length
Booth width
Booth basement height
Weight:
Booth inside length 3000 mm
Booth inside width 1800 mm
Superstructure height approx. 3250 mm
more or less weihgt per 500 mm length:
3x400 V / 50 Hz
(other voltages and
frequencies on request)
min. 6 bar / max. 10 bar
0.7 m/sec
max. 18 Nm³/h
max. 1.3 g/m³
max. 0.1 mg/m³
max. 18 Nm³/h
max. 4.5 m (in the interior)
1,6/1,8/2,0 m
0,6 m
approx. 3300 kg
approx. 300 kg
Technical data • 25
