PS Gigabit Ethernet pin assignment is as follows:
Signal Name
PHY1_TXCK
PHY1_TXD0
PHY1_TXD1
PHY1_TXD2
PHY1_TXD3
PHY1_TXCTL
PHY1_RXCK
PHY1_RXD0
PHY1_RXD1
PHY1_RXD2
PHY1_RXD3
PHY1_RXCTL
PHY1_MDC
PHY1_MDIO
PL Gigabit Ethernet pin assignment is as follows:
Signal Name
PHY2_TXCK IO_L20N_T3L_N3_AD1N_64
PHY2_TXD0 IO_L24P_T3U_N10_64
PHY2_TXD1 IO_L24N_T3U_N11_64
PHY2_TXD2 IO_L23P_T3U_N8_64
PHY2_TXD3 IO_L23N_T3U_N9_64
PHY2_TXCTL IO_L20P_T3L_N2_AD1P_64
www.alinx.com
Figure 11-1: Connection between ZYNQ and GPHY
Pin Name
PS_MIO64_502
PS_MIO65_502
PS_MIO66_502
PS_MIO67_502
PS_MIO68_502
PS_MIO69_502
PS_MIO70_502
PS_MIO71_502
PS_MIO72_502
PS_MIO73_502
PS_MIO74_502
PS_MIO75_502
PS_MIO76_502
PS_MIO77_502
Pin Name
Pin Number
Ethernet 1 RGMII transmission clock
AD32
Ethernet 1 transmission data bit 0
AE29
Ethernet 1 transmission data bit 1
AD33
Ethernet 1 transmission data bit 2
AE30
Ethernet 1 transmission data bit 3
AE33
Ethernet 1 transmission enable signal
AE32
Ethernet 1 RGMII reception clock
AF30
Ethernet 1 reception data Bit 0
AF31
Ethernet 1 reception data Bit 1
AF32
Ethernet 1 reception data Bit 2
AG30
Ethernet 1 reception data Bit 3
AG33
Ethernet 1 reception data valid signals
AF33
Ethernet 1 MDIO manage clock
AH31
Ethernet 1 MDIO manage data
AG31
Pin No.
AM20
AJ22
AK22
AJ21
AJ20
AM21
Z19 User Manual
Remarks
Remarks
Ethernet 2 RGMII transmission clock
Ethernet 2 transmission data bit 0
Ethernet 2 transmission data bit 1
Ethernet 2 transmission data bit 2
Ethernet 2 transmission data bit 3
Ethernet 2 transmit the enable
