2.3.2 Mounting the Device to a Panel
For panel installations, the RUGGEDCOM RST916P can be equipped with panel
adapters that allow the device to be attached to a panel in either a rear-mount or
side-mount orientation.
1
RUGGEDCOM RST916P
Equipment Manual, 11/2023, C79000-G8976-1489-06
DIN Rail
1
DIN Rail Adapter
2
Figure 2.2 Removing the Device from a DIN Rail
Swing the bottom of the device away from the DIN rail.
Lift the device off the DIN rail.
1
Rear-Mount Orientation
2.3.2 Mounting the Device to a Panel
3
1
2
1
2
Installing the Device
