2.4.2 Mounting the Device to a Panel
For panel installations, the RUGGEDCOM RS900G can be equipped with panel
adapters that allow the device to be attached to a panel using screws.
To mount the device to a panel, do the following:
1.
RUGGEDCOM RS900G
Equipment Manual, 10/2023, C79000-G8976-1025-10
1
DIN Rail
1
DIN Rail Adapter
2
Figure 2.2 Removing the Device from a DIN Rail
Swing the bottom of the device away from the DIN rail.
Lift the device off the DIN rail.
Loosen the screws for the panel adapters located at the top and bottom of the
device.
1
Panel Adapter
1
2.4.2 Mounting the Device to a Panel
2
2
Installing the Device
2
1
3
1
2
1
9
