5.9 Dimension Drawings
5.9
Dimension Drawings
Note
All dimensions are in millimeters, unless otherwise stated.
Figure 5.1
Figure 5.2
32
116.1
Overall Dimensions
116.1
78.6
60.0
4.8
Panel Mount Dimensions (Rear Mount Orientation)
164.5
165.3
RUGGEDCOM RST916P
Equipment Manual, 11/2023, C79000-G8976-1489-06
