Siemens SIMATIC NET RUGGEDCOM RST916P Equipment Manual page 19

Installing the Device
2.3.1 Mounting the Device on a DIN Rail
2.
3.
Removing the Device
To remove the device from a DIN rail, do the following:
1.
10
DIN Rail
1
DIN Rail Adapter
2
Figure 2.1 Mounting the Device to a DIN Rail
Insert a flathead screwdriver into the slot of the sliding release and move it
down.
Push the device against the bottom of the DIN rail, then let go of the sliding
release to latch the device.
Insert a flathead screwdriver into the slot of the sliding release and move it
down.
1
1
2
2
3
