6.6 PCI Slots

PCI interrupts
OnboardDevice
PCIA1
PCI2
PCIA1, PCI2: 32-bit PCI slot
A Signal
1 TRST_L
2 +12V
3 TMS
4 TDI
5 +5V
6 INTA_L
7 INTC_L
8 +5V
9 Reserved
10 +5V
11 Reserved
12 Ground
13 Ground
14 Reserved
15 RST_L
16 +5V
17 GNT_L
18 Ground
19 Reserved
20 AD[30]
21 +3.3V
22 AD[28]
23 AD[26]
24 Ground
25 AD[24]
26 IDSEL
27 +3.3V
28 AD[22]
29 AD[20]
30 Ground
31 AD[18]
Page 18
Pin INTA# Pin INTB#
X1_INTA# X1_INTB# X1_INTC#
X1_INTB# X1_INTC# X1_INTD#
A1
B1
B Signal
1 -12V
2 TCK
3 Ground
4 TDO
5 +5V
6 +5V
7 INTB_L
8 INTD_L
9 PRSNT1_L
10 Reserved
11 PRSNT2_L
12 Ground
13 Ground
14 Reserved
15 Ground
16 CLK
17 Ground
18 REQ_L
19 +5V
20 AD[31]
21 AD[29]
22 Ground
23 AD[27]
24 AD[25]
25 +3.3V
26 C/BE[3]_L
27 AD[23]
28 Ground
29 AD[21]
30 AD[19]
31 +3.3V
Pin INTC# Pin INTD#
X1_INTD#
X1_INTA#
A Signal
32 AD[16]
33 +3.3V
34 FRAME_L
35 Ground
36 TRDY_L
37 Ground
38 STOP_L
39 +3.3V
40 Reserved
41 Reserved
42 Ground
43 PAR
44 AD[15]
45 +3.3V
46 AD[13]
47 AD[11]
48 Ground
49 AD[09]
50 KEYWAY
51 KEYWAY
52 C/BE[0]_L
53 +3.3V
54 AD[06]
55 AD[04]
56 Ground
57 AD[02]
58 AD[00]
59 +5V
60 REQ64_L
61 +5V
62 +5V
Express-BASE User's Manual
IDSEL
AD20
AD21
A62
B62
B Signal
32 AD[17]
33 C/BE[2]_L
34 Ground
35 IRDY_L
36 +3.3V
37 DEVSEL_L
38 Ground
39 LOCK_L
40 PERR_L
41 +3.3V
42 SERR_L
43 +3.3V
44 C/BE[1]_L
45 AD[14]
46 Ground
47 AD[12]
48 AD[10]
49 Ground
50 KEYWAY
51 KEYWAY
52 AD[08]
53 AD[07]
54 +3.3V
55 AD[05]
56 AD[03]
57 Ground
58 AD[01]
59 +5V
60 ACK64_L
61 +5V
62 +5V
