Feature
PEG Port Configuration
VT-d
Above 4GB MMIO BIOS
assignment
8.5.2. Chipset > PCH-IO Configuration
Feature
PCH-IO Configuration ►
PCH-IO Configuration
PCI Express Configuration ►
PCI Express Configuration
PCI Express Clock Gating
Pcie Pll SSC
SATA Configuration ►
SATA Configuration
SATA Controller(s)
SATA Mode Selection
BIOS Setup
Options
Info only
Disabled
Enabled
Disabled
Enabled
Options
Submenu
Info only
Submenu
Info only
Disabled
Enabled
Auto
0.0%
0.1%
0.2%
0.3%
0.4%
0.5%
0.6%
0.7%
0.8%
0.9%
1.0%
1.1%
1.2%
1.3%
1.4%
1.5%
1.6%
1.7%
1.8%
1.9%
2.0%
Submenu
Info only
Disabled
Enabled
AHCI
Intel RST Premium With
Intel Optane System
Acceleration
Description
Enable or Disable VT-d capability
Enable or disable above 4GB MemoryMappedIO BIOS
assignment This is enabled automatically when
Aperture Size is set to 2048MB.
Description
PCI Express Configuration settings
PCI Express Clock Gating Enable/Disable for each
root port.
Pcie Pll SSC percentage. AUTO - Keep hw default, no
BIOS override. Range is 0.0%-2.0%.
SATA Device Options Settings
Enable/Disable SATA Device
Determines how SATA controller(s) operate
