2.4.

Internal Headers and Connectors

PCI Express Slots
USB
SATA
Serial
Other
2.5.

Form Factor

Mini-ITX: 170mm x 170mm
2.6.

SEMA Board Controller

ADLINK Smart Embedded Management Agent (SEMA)
• Voltage/Current monitoring
• Logistics and Forensic information
• Flat Panel Control
• General Purpose I2C
• Failsafe BIOS (dual BIOS)
• Watchdog Timer and Fan Control
4
PCIe x16 (Gen3)
PCIe x1 (Gen2)
1x full-size Mini-PCIe slot (Q370: PCIe x1, mSATA and USB 2.0 / H310: PCIe x1)
1x M.2 (M key, 2242, NVMe support; H310: PCIe x1 Gen2 signal)
2x USB 3.0 onboard header (Q370)
1x USB 2.0 onboard header (H310)
1x USB 3.0 vertical connector (H310 only supports USB2.0)
3x SATA 6 Gbps ports (Jumper select NA/3.3V/5V for SATA1 and SATA2 to deliver power by
SATA pin7; Default is NA)
2x SATA power connectors
3x RS-232 headers, 1x RS-232/422/485 header (supports NC/5V/12V power by jumper selection)
1x CCTALK x2 on internal header
Front Panel Header
Audio Header
Feature Connector Header
SPI Header
ATX Power Connector (14-pin)
