2.7.

Video

GPU Feature Support
Display Interface Support
2.8.

Audio

Integrated
Audio Codec
Interfaces
2.9.

LAN

Realtek
Interface

2.10. Trusted Platform Module (TPM)

Chipset
Type

2.11. Power Specification

Power Modes
Standard Voltage Input
Power Management
Power States
Specifications
Intel® 9th generation LP graphics core architecture with up to 18 execution units
supporting DirectX 11/12, OGL4.3/4.4, and up to three independent, simultaneous
displays
3x DisplayPort v1.2 with resolution up to
2x DisplayPort (H310))
Intel® HD Audio on chipset
Realtek ALC888
• 7.1 channel audio via 5 jacks and S/PDIF output on rear I/O
• 7.1 channel audio signals and S/PDIF output via internal header
2x Realtek RTL8119-CG Ethernet controller
10/100/1000 GbE connection
Infineon SLB9665XT
TPM2.0
AT and ATX mode
ATX = 12VDC ±5%, 5Vsb ±5% or AT = 12V ±5%
ACPI 4.0 compliant
Supports C1-C6, S0, S1, S4, S3, S5, (Wake-on-USB S3/S4, WoL S3/S4/S5)
4096 x 2304 @ 60Hz
(3x DisplayPort (Q370) ,
AmITX-CF-G
5
