ADLINK Technology AmITX-CF-G User Manual page 14

ATX mode (with standard power supply 24-pin)
System S5 mode with ECO enabled
3.3A(A)orange 0.01
5V(A)red 0.01
+12V(A)yellow 0.01
5VSB(A)purple 0.02
Power
0.303
Consumption(W)
ATX mode (with 12V adapter)
Processor i3-8100T 3.1 35W
Chipset Q370
Memory 16G 2400MHz
Graphics Q370
HDD M.2 (S42) 3TG6-P M.2 (S42) 3TG6-P
OS Win 10 Enterprise
Windows Idle mode/Enable EIST/Enable Turbo boost
3.3A(A) N/A
5V(A) N/A
12V(A) 1.32
5VSB(A) N/A
Power
15.84
Consumption(W)
Windows Idle mode/Disable EIST/Disable Turbo boost
3.3A(A) N/A
5V(A) N/A
12V(A) 1.55
5VSB(A) N/A
Power
18.6
Consumption(W)
Windows Typical mode/Enable EIST/Enable Turbo boost
3.3A(A) N/A
5V(A) N/A
12V(A) 13.77
5VSB(A) N/A
Power
165.24
Consumption(W)
8
0.01 0.01
0.01 0.01
0.01 0.01
0.02 0.03
0.303 0.353
i5-8500T 2.10 35W i7-9700TE 1.8 35W i5-9500E 3.0 65W i7-8700 3.2 65W
Q370 Q370
16G 2400MHz 16G 2400MHz
Q370 Q370
M.2 (S42) 3TG6-P
Win 10 Enterprise Win 10 Enterprise
N/A N/A
N/A N/A
1.19 1.1
N/A N/A
14.28 13.2
N/A N/A
N/A N/A
1.48 1.35
N/A N/A
17.76 16.2
N/A N/A
N/A N/A
14.41 16.35
N/A N/A
172.92 196.2
0.01 0.02
0.01 0.02
0.01 0
0.04 0.01
0.403 0.216
Q370 Q370
16G 2400MHz 16G 2400MHz
Q370 Q370
M.2 (S42) 3TG6-P M.2 (S42) 3TG6-P
Win 10 Enterprise Win 10 Enterprise
N/A N/A
N/A N/A
1.49 1.51
N/A N/A
17.88 18.12
N/A N/A
N/A N/A
1.73 1.88
N/A N/A
20.76 22.56
N/A N/A
N/A N/A
19.35 21.66
N/A N/A
232.2 259.92
Specifications
