1.
OVERVIEW.......................................................................................................................................... 1
2.
INSTALLATION................................................................................................................................... 3
2.1. VIDEO CONNECTION................................................................................................................ 3
2.1.1. MFX-HD in Encode Mode ............................................................................................... 3
2.1.2. MFX-HD in Decode Mode ............................................................................................... 4
2.2. AUDIO CONNECTIONS ............................................................................................................. 4
2.3. GENLOCK REFERENCE ........................................................................................................... 5
3.
SPECIFICATIONS............................................................................................................................... 6
3.1. SERIAL VIDEO INPUTS/OUTPUTS .......................................................................................... 6
3.2. JPEG2000 OVER SDI INPUTS/OUTPUTS ................................................................................ 6
3.3. JPEG2000 OVER ASI INPUTS/OUTPUTS ................................................................................ 6
3.4. AES AUDIO INPUTS/OUTPUTS................................................................................................ 6
3.5. ENCODING PARAMETERS....................................................................................................... 6
3.6. REFERENCE INPUT .................................................................................................................. 7
3.7. ENCODING/DECODING DELAY ............................................................................................... 7
3.8. ELECTRICAL ............................................................................................................................. 7
3.9. PHYSICAL .................................................................................................................................. 7
4.
STATUS INDICATORS AND DISPLAYS ........................................................................................... 8
4.1. EMBEDDED AUDIO STATUS LEDS ......................................................................................... 9
5.
CARD EDGE CONTROLS ................................................................................................................ 11
6.
ENCODE CARD EDGE MENU SYSTEM.......................................................................................... 12
6.1. TOP LEVEL ENCODE MENU STRUCTURE ........................................................................... 12
6.2. CONFIGURING THE AUDIO CONTROLS............................................................................... 12
6.2.1. Setting the SRC Mode................................................................................................... 13
6.2.2. Setting the C-bit Control ................................................................................................ 13
6.2.3. Setting Audio Input Sources.......................................................................................... 13
7772MFX-HD JPEG2000 SD & HD Encoder and Decoder
TABLE OF CONTENTS
Revision 1.2
7700 MultiFrame Manual
Advertisement
Table of Contents
Related Manuals for evertz 7772MFX-HD
Summary of Contents for evertz 7772MFX-HD
-
Page 1: Table Of Contents
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder TABLE OF CONTENTS OVERVIEW............................1 INSTALLATION........................... 3 2.1. VIDEO CONNECTION........................ 3 2.1.1. MFX-HD in Encode Mode ....................3 2.1.2. MFX-HD in Decode Mode ....................4 2.2. AUDIO CONNECTIONS ......................4 2.3. - Page 2 7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 6.2.4. Setting the Audio Input Sources for AES Channels 1-16 ..........13 6.3. CONFIGURING THE TRANSPORT STREAM CONTROL ............15 6.3.1. Setting the Program Number..................15 6.3.2. Setting the PMT PID Number..................15 6.3.3.
- Page 3 7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 7.4.1. Sets the Program Number..................... 27 7.4.2. Reset the TS Statistics ....................27 7.5. CONFIGURING THE HEADPHONE MONITOR............... 27 7.5.1. Setting the Headphone Volume ..................27 7.5.2. Selecting the Source for the Headphone Monitoring............. 28 7.6.
- Page 4 Figure 9-15: Faults Tab in Decode Mode ......................50 Tables Table 2-1: AES INPUT/OUTPUT Audio Connector Pin Out ................. 4 Table 2-2: Example AES Audio Breakout Cable (Evertz Part # WPAES8-BNCM-6F)......... 5 Table 4-1: Audio Group Status LEDs........................9 Table 4-2: AES Input Channel Presence LEDs ....................10 Table 6-1: Top Level Menu Structure........................
- Page 5 Evertz products are for informational use only and are not warranties of future performance, either express or implied. The only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
- Page 6 7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder This page left intentionally blank Revision 1.2...
-
Page 7: Overview
Eight separate stereo unbalanced outputs The 7772MFX-HD can be configured on the fly as an encoder (HD SDI > ASI or SDTI) or a decoder (ASI or SDTI > HD SDI). Check the software to see which mode is enabled. -
Page 8: Figure 1-1: 7772Mfx-Hd In Encode Mode Block Diagram
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder TS mux 270Mb/s HD Inputs JPEG2000 Cable Bypass Equalizer S / P Video Memory Video + P / S Data (SMPTE 292M) Compression Driver Audio Outputs Output Timing Generator... -
Page 9: Installation
7772MFX-HD JPEG2000 SD & HD Encoder and Decoder INSTALLATION The 7772MFX-HD comes with a companion rear plate, occupying two slots in the 7700FR frame. For information on mounting the rear plate and inserting the module into the frame see section 3 of the 7700FR chapter. -
Page 10: Mfx-Hd In Decode Mode
Table 2-1: AES INPUT/OUTPUT Audio Connector Pin Out The 7772MFX-HD module is shipped with two breakout cables for the DB-15 connector (Evertz Part # WPAES8-BNCM-6F), which can be used to facilitate wiring the AES audio connections. The pin out of the cables is shown in Table 2-2. -
Page 11: Genlock Reference
GENLOCK REFERENCE For proper synchronization of the input/output video, the module MUST be locked to a Genlock signal of the output video format. It is mandatory that a Genlock source is provided to the 7772MFX-HD during operation. GENLOCK: This BNC is for connecting a bi-level or tri-level sync reference and is auto-detected by the module. -
Page 12: Specifications
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder SPECIFICATIONS 3.1. SERIAL VIDEO INPUTS/OUTPUTS Standard: SMPTE 292M, (1080i/59.94, 1080i/50, 720p/59.94, 720p/50) SMPTE 259M (480i/29.97, 576i/25) Number of Inputs: 1 (Encoder) Number of Outputs: 2 (Decoder) Connector: BNC per IEC 61169-8 Annex A 3.2. -
Page 13: Reference Input
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 3.6. REFERENCE INPUT Connector: 1 BNC per IEC 61169-8 Annex A Type: NTSC/PAL Color Black (1V p-p) or composite bi-level sync (525i/59.94 or 625i/50) 300mV Termination: 75Ω jumper selectable 3.7. -
Page 14: Status Indicators And Displays
7772MFX-HD JPEG2000 SD & HD Encoder and Decoder STATUS INDICATORS AND DISPLAYS The 7772MFX-HD module has 17 LED status indicators on the front card edge to show operational status of the card at a glance. Figure 4-1 shows the location of the LEDs and card edge controls. -
Page 15: Embedded Audio Status Leds
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder FPGA CONFIG: This LED will be RED and ON when the FPGA is loading on power up. The LED is OFF during normal module operation. 4.1. EMBEDDED AUDIO STATUS LEDS Four LEDs located on the lower end of the main board of the module (near the card extractor) indicate which embedded audio groups are present in the input video. - Page 16 7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder AES Input Colour AES Input Channel Status Channel LED AES input channel 1 is not present Green AES input channel 1 is present Yellow AES input channel 1 is present with encoded Dolby...
-
Page 17: Card Edge Controls
NOTE: During card edge menu system navigation, if all the Audio LEDs are OFF, the user is at the Top Level menu. The 7772MFX-HD modules are also equipped with an eight-position DIP switch. Currently, the DIP switches are not functional and are reserved for future use. -
Page 18: Encode Card Edge Menu System
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder ENCODE CARD EDGE MENU SYSTEM 6.1. TOP LEVEL ENCODE MENU STRUCTURE Table 6-1 provides a brief description of the top-level menu tree that appears when you enter the card edge menu system. -
Page 19: Setting The Src Mode
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 6.2.1. Setting the SRC Mode Audio Control This control sets the bypass mode of the audio sample rate converter. When Enabled, audio is sample rate converted at 48 kHz, which is... - Page 20 7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder Audio Control This parameter will select the source for audio channels 3 and 4. SRCS The source can be the demuxed audio from the input signal or the SRC34 external AES 2 Input.
-
Page 21: Configuring The Transport Stream Control
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 6.3. CONFIGURING THE TRANSPORT STREAM CONTROL The transport stream configuration is used to set up PID’s Number and program number. The PID number needs to be set when using ASI output for PMT, Video, luminance, video chrominance, audio and VANC. -
Page 22: Setting The Luminance Pid Number
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 6.3.4. Setting the Luminance PID Number Transport Stream Control This control selects the luminance PID Number. Luminance is carried separately from chrominance in the 7772MFX-HD. LUMI 32 to 8191 The luminance PID range is from 32 to 8191. -
Page 23: Selecting The Source For The Headphone Monitoring
DMX8 6.5. DISPLAYING THE MODULE STATUS The Status menus are used to show the status of various parameters of the 7772MFX-HD. The chart below shows the items available in the Status menu. Sections 6.5.1 to 6.5.5 provide detailed information about each of the menu items. -
Page 24: Checking Fpga 2 Revision
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 6.5.3. Checking FPGA 2 Revision Status The status parameter will report the revision of FPGA 2 (J2K sub board) on the module. F2RV Ex. “8” 6.5.4. Checking FPGA 3 Revision Status The status parameter will report the revision of FPGA 3 on the module. -
Page 25: Configuring Miscellaneous Parameters
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 6.6. CONFIGURING MISCELLANEOUS PARAMETERS The Miscellaneous menu is used to configure miscellaneous parameters, to enable VistaLINK control, to ® display orientation, and to perform a factory reset. The chart below shows the items available in the Miscellaneous menu. -
Page 26: Resetting The Module To Its Factory Defaults
Select NO to not reset the module to factory settings. 6.6.4. Switching Encoder and Decoder Mode Miscellaneous Switches the card between encode or decode mode. IMGS The 7772MFX-HD can be set as an encoder or a decoder. To Decoder TDEC Select NO to leave the mode unchanged. To Encoder TENC Select TDEC (To Decoder) to change the encoder to a decoder. -
Page 27: Setting The Transport Mode
YCRA 1 to 10 For example, if YCRA is set to 5 (default), the 7772MFX-HD will output 5 times more luma samples than chroma samples. It would be a 5:1 ratio. The default value is 5. -
Page 28: Decode Card Edge Menu System
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder DECODE CARD EDGE MENU SYSTEM 7.1. TOP LEVEL DECODE MENU STRUCTURE Table 7-1 provides a brief description of the top level menu tree that appears when the user enters the card edge menu system. -
Page 29: Setting The Vertical Phase
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 7.2.1. Setting the Vertical Phase Video Control This control selects the vertical delay of the output video signal in respect to the input video. The range of values is based on the VDLY operating (output) video standard of the module. -
Page 30: Setting The Loss Of Video Mode
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 7.2.4. Setting the Loss of Video Mode Video Control This control selects the output behaviour of the card when the input goes missing. LOVM BLACK Select BLK to set the output to black and maintain the HD SDI... -
Page 31: Setting The Coarse Audio Delay
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 7.3.1. Setting the Coarse Audio Delay Audio Control This control adjusts the audio delay in terms of video frames (coarsely). The delay is respective of the input video. The range of the parameter... -
Page 32: Setting The C-Bit Control
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 7.3.4. Setting the C-bit Control Audio Control This control determines how the AES channel status bits are handled when being routed from input to output. When set to preserve, the... -
Page 33: Sets The Program Number
9999 The default value is –1. 7.4.2. Reset the TS Statistics Transport Stream Control The 7772MFX-HD collects TS statistics referring to lost packets, TSST errors, etc. This control will reset the statistics to 0. Select 0 to keep the statistics as is. -
Page 34: Selecting The Source For The Headphone Monitoring
7.6. DISPLAYING THE MODULE STATUS The status menus are used to show the status of various parameters of the 7772MFX-HD. The chart below shows the items available in the status menu. Sections 7.6.1 to 7.6.6 provide detailed information about each of the menu items. -
Page 35: Checking Fpga 3 Revision
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 7.6.4. Checking FPGA 3 Revision Status The status parameter will report the revision of FPGA 3 (audio sub-board) on the module. F3RV Eg. “9” 7.6.5. Checking the Input Video Standard Status The status parameter will report the input video standard. -
Page 36: Enabling Vistalink
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 7.7.1. Enabling VistaLINK Control of the Module ® Miscellaneous This control configures the VistaLINK control of the module. ® VLNK Select RMTE to enable VistaLINK control of the module. The user is... -
Page 37: Switching Encoder And Decoder Mode
7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 7.7.4. Switching Encoder and Decoder Mode Miscellaneous This control switches the encoder and decoder mode. IMGS The 7772MFX-HD can be set as an encoder or a decoder. To Decoder TDEC Select NO to leave the mode unchanged. To Encoder TENC Select TDEC (To Decoder) to change the encoder to a decoder. -
Page 38: Jumpers
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder JUMPERS MODULE STATUS SIGNAL PRESENT Bypass GCLK EVERTZ (B) 7700PH4 Upgrade Group 1 Group 2 Group 3 Group 4 FRAME STATUS SFF POWER +12V Figure 8-1: Location of Jumpers – Rev B Main Board... -
Page 39: Configuring The Module For Firmware Upgrades
J16 into the RUN position, remove the upgrade cable and re-install the module. The module is now ready for normal operation. The Upgrade baud rate for the 7772MFX-HD module is 115200 baud. 8.3. SELECTING WHETHER THE GENLOCK REFERENCE INPUT IS TERMINATED... -
Page 40: Vistalink ® Remote Monitoring/Control
Evertz VistaLINK enabled fiber optic products. ® 2. Managed devices, (such as 7772MFX-HD card), each with a unique address (OID), communicate with the NMS through an SNMP Agent. Evertz VistaLINK enabled 7700 series modules reside in the 3RU ®... -
Page 41: Parameters For Mfx-Hd In Encode Mode
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 9.2. VISTALINK PARAMETERS FOR MFX-HD IN ENCODE MODE ® The following parameters can be remotely monitored through the VistaLINK interface. ® 9.2.1. VistaLINK GENERAL TAB ® Figure 9-1: General Tab in Encode Mode 7772MFX-HD - 35 Revision 1.2... -
Page 42: General Tab
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder Parameter Description This field indicates whether the 7772MFX-HD is under local control or Vistalink Enable VistaLINK control. ® FPGA 1 Revision This field displays the revision code of the main board FPGA. -
Page 43: Vistalink Program Select Monitor Tab
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 9.2.2. VistaLINK PROGRAM SELECT MONITOR TAB ® Figure 9-2: Program Select Monitor Tab in Encode Mode 7772MFX-HD - 37 Revision 1.2... -
Page 44: Program Select Monitor Tab
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder Parameter Description This control enables the user to switch the output transport between Output Format SDI and ASI. HD Video Compression This control enables the user to set the HD Video Compression rate. -
Page 45: Vistalink
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 9.2.3. VistaLINK AUDIO INPUT TAB ® Figure 9-3: Audio Input Tab in Encode Mode 7772MFX-HD - 39 Revision 1.2... -
Page 46: Vistalink
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder Parameter Description This control sets the mode of the sample rate converter. SRC Mode The default value should be 'auto'. Embedder Group 1 to 4 This control enables the user to enable or disable each specific embedder Enable group. -
Page 47: Faults Tab
If fast HD to SD, or SD to HD SD Bypass Mode switching is required, SD Bypass Mode should be set to input and SD- SDI input must be genlocked to the same source as 7772MFX-HD, however AES audio embedding is not supported. Table 9-4: VistaLINK Misc Control Tab ®... -
Page 48: Vistalink
9.3.1. VistaLINK GENERAL TAB ® Figure 9-6: General Tab in Decode Mode Parameter Description This field indicates whether the 7772MFX-HD is under local control or Vistalink Enable VistaLINK control. ® This field displays the revision code of the main board FPGA. -
Page 49: Vistalink
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 9.3.2. VistaLINK I/O MONITOR TAB ® Figure 9-7: I/O Monitor Tab in Decode Mode Parameter Description This field displays the detected input video standard. The parameter will Input Standard indicate the current supported input format detected by the card. -
Page 50: Vistalink
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 9.3.4. VistaLINK ASI PID VIEW TAB ® The ASI PID View tab displays a table of all input TS elementary stream PIDs in the input stream (TS Mode Only). -
Page 51: Vistalink Program Select Monitor Tab
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 9.3.6. VistaLINK PROGRAM SELECT MONITOR TAB ® Figure 9-11: Program Select Monitor Tab in Decode Mode 7772MFX-HD - 45 Revision 1.2... -
Page 52: Program Select Monitor Tab
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder Parameter Description This button resets all error counters. Reset Error Counters Program Number Provides the program description for this program. Sync Loss Counter Counter for ASI input TS stream lost of synchronization byte. -
Page 53: Vistalink Video Output Tab
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 9.3.7. VistaLINK VIDEO OUTPUT TAB ® Figure 9-12: Video Output Tab in Decode Mode Parameter Description Vertical Phase Vertical phase adjustment of current video standard. Horizontal Phase Horizontal phase adjustment of current video standard. -
Page 54: Vistalink Audio Output Tab
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 9.3.8. VistaLINK AUDIO OUTPUT TAB ® Figure 9-13: Audio Output Tab in Decode Mode Parameter Description Coarse Audio Delay Allows the user to adjust the coarse audio delay. Fine Audio Delay Allows the user to adjust the fine audio delay. -
Page 55: Vistalink Misc Control Tab
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 9.3.9. VistaLINK MISC CONTROL TAB ® Figure 9-14: Misc Control Tab in Decode Mode Parameter Description This parameter is the source selection for headphone Headphone Source monitoring. Headphone Volume This parameter is the headphone volume adjustment. -
Page 56: Vistalink Faults Tab
7700 MultiFrame Manual 7772MFX-HD JPEG2000 SD & HD Encoder and Decoder 9.3.10. VistaLINK FAULTS TAB ® Figure 9-15: Faults Tab in Decode Mode Parameter Description Genlock Presence Indicates genlock presence. Input Video Presence Indicates video presence. Table 9-12: VistaLINK Faults Tab ®...
