  • Page 5: Overview

    This module is useful in mobile broadcast vehicles and broadcast plants to compare primary and secondary video feeds. This 7700 series module provides 3 reclocked primary outputs and 1 reclocked secondary output. The 7760VMS-HD occupies two card slots in the 3RU frame which will hold up to 7 modules, or 1 slot in the 1RU frame which will hold up to 3 modules.
  • Page 6: Installation

    7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter INSTALLATION The 7760VMS-HD comes with a companion rear plate that occupies two slots in the frame. information on inserting the module into the frame see the 7700FR chapter section 3. Figure 2-1: 7760VMS-HD Rear IO Module 2.1.
  • Page 7: Genlock Reference

    7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter HD/SDI MONITOR OUTPUT: This BNC connector provides a split screen output in the same video standard as the input video. The left portion of the picture comes from Input A and the right portion of the picture comes from Input B.
  • Page 8: Figure 2-3: Typical Gpo Circuitry

    7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter +3.3V Figure 2-3: Typical GPO Circuitry The GPIO cables can be secured into the removable portion of the terminal strips using a small screwdriver. The removable part of the terminal strip is then inserted into the rear panel and secured using the hold down screws.
  • Page 9: Specifications

    7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter SPECIFICATIONS 3.1. SERIAL VIDEO INPUTS Standard: 1.485 Gb/sec SMPTE 292M (1080i/50, 1080i/59.94, 720p/50, and 720p/59.94) or 270 Mb/s SMPTE 259M (525/59.94 and 625/50) auto-detects standard SMPTE 260M, SMPTE 274M, SMPTE 296M, SMPTE 349M...
  • Page 10: Gpio Control Port

    7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter 3.5. GPIO CONTROL PORT Number of Inputs: Number of Outputs: 2 Type: Opto-isolated, active low with internal pull-ups to +5 or +12V (jumper settable) Connector: 6 pins removable terminal block Signal Level: closure to ground 3.6.
  • Page 11: Status Indicators

    7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter STATUS INDICATORS The 7760VMS-HD has 9 LED Status indicators on the main circuit board front card edge to show operational status of the card at a glance. Figure 7-1 shows the location of the LEDs and card edge controls.
  • Page 12: Audio Status Leds

    7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter 4.1. AUDIO STATUS LEDs Four LEDs located on the lower edge of the module (near the card extractor) indicate which audio groups are present in the input video. Audio group LED 1 is located closest to the center of the module.
  • Page 13: Card Edge Controls

    7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter CARD EDGE CONTROLS The 7760VMS-HD is equipped with an 8 position DIP switch, toggle switch, push button and a 4 character dot matrix display to allow the user to select various functions.
  • Page 14: Card Edge Menus

    7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter CARD EDGE MENUS 6.1. NAVIGATING THE CARD EDGE MENU SYSTEM Status monitoring and control over the card’s parameters is provided via the 4-digit alphanumeric display located on the card edge. The toggle switch and pushbutton are used to navigate through a menu system to set various parameters for the module.
  • Page 15: Selecting The Reference Input Type

    7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter 6.2.1. Selecting the Reference Input Type GTSD This control selects the genlock reference type being used. 525/59.94 colour black 720p/50 Tri-level sync 7P50 720p/59.94 Tri-level sync 7P59 1I50 1080i/50 Tri-level sync 1I59 1080i/59.94 Tri-level sync...
  • Page 16: Configuring The Horizontal Split Line

    7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter 6.2.5. Configuring the Horizontal Split Line HSPL This controls the split line horizontally between inputs A and B. 0 to Max The HSPL value is an offset that is applied from the leftmost position (vertically).
  • Page 17: Configuring The Orientation Of The Text On The Display

    7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter 6.2.7. Configuring the Orientation of the Text On the Display DISP This control allows the user to select a horizontal or vertical orientation for the displays to accommodate mounting the module in the 3RU or 1RU VERT frames.
  • Page 18: Location Of Leds And Jumpers

    7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter LOCATION OF LEDS AND JUMPERS MODULE STATUS (2)7710FPB1 UPGRADE GENLOCK INPUT A INPUT B AUDIO 1 75 ohms Hi-Z AUDIO 2 AUDIO 3 AUDIO 4 SFF POWER FRAME STATUS +12V GPI SELECT Figure 7-1: LED and Jumper Locations 7.1.
  • Page 19: Selecting Whether The Genlock Reference Input Is Terminated

    7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter 7.3. SELECTING WHETHER THE GENLOCK REFERENCE INPUT IS TERMINATED TERM: The TERM jumper J17 located at the rear of the module is used to terminate the genlock loop input. Then it is in the 75R position a 75 ohm terminating resistor will connect the input to ground.
  • Page 20: Vistalink ® Remote Monitoring/Control

    1. An SNMP manager, also known as a Network Management System (NMS), is a computer running special software that communicates with the devices in the network. Evertz VL-Fiber demo Manager graphical user interface (GUI), third party or custom manager software may be used to monitor and control Evertz VistaLINK enabled fiber optic products.
  • Page 21: Vista Link ® Traps

    7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter 8.3. VistaLINK CONTROLLED PARAMETERS ® Parameter Description Sets the Genlock video standard Genlock Standard Monitoring Output LOV Sets the Split Screen behaviour when there is a loss of input video Behaviour Monitoring Output Aspect Ratio...
  • Page 22 7700 MultiFrame Manual 7760VMS-HD HD Video Monitoring Splitter This page left intentionally blank Page - 18 Revision 0.3...
