Operation

a
This section describes the operation of the DTP3 T 101 D. Topics include:
•

Front Panel Indicator

DTP3 T 101 D
Front Panel
•
Operation
Front Panel Indicator
A
HDMI IN
HDMI IN
a
DTP3 T 101 D
Figure 9. DTP3 T 101 D Front Panel Indicator
Front Panel
Operation
After the transmitter and the connected devices are powered up, the system is fully operational. If any problems
are encountered, ensure all cables are routed and connected properly.
NOTE: The transmitter can be configured via PCS (see the DTP3 T 101 D Help File) and SIS commands (see
SIS Configuration and Control
connected or an offline device is selected.

Resetting

The rear panel Reset button (see
ballpoint pen, or small screwdriver to access the recessed button.
ATTENTION:
• Review the reset modes carefully. Some reset modes delete all user loaded content and revert the
device to default configuration.
•
Analysez minutieusement les différents modes de réinitialisation. Certains modes de réinitialisation
suppriment l'intégralité du contenu chargé de l'utilisateur et remettent l'appareil au mode de
configuration par défaut.
NOTES:
• The transmitter can also be reset to its factory default settings using SIS commands (see
page 15) or PCS (see the DTP3 T 101 D Help File).
G
F
SEND POWER
DTP3 T 101 D
Power and Signal LED — Two‑color front panel LED lights to indicate signal
A
and power status:
•
Amber — Unit is receiving power but no signal on the HDMI input.
• Green — Unit is receiving power and a signal is present on the HDMI input
when Tx is connected to a Rx and display.
on page 23). Product help files are available in PCS when a device is
figure 4, on page 7) initiates two levels of resets. Use a pointed stylus,
C
B
C
RESET
D
OUT
E
HDBT
OFF DTP
DTP3 T 101 D
Rear Panel
Resets
DTP3 T 101 D • Operation
on
13
