Device Menu

The device menu contains options pertaining to device connection, configuration, and information. For details
about these options, see the DTP3 T 101 D PCS Help File.
•
Disconnect — Disconnect the device from the PCS program
and close the Device tab.
•
Settings — Open a submenu with the following options:
•
Hardware Settings — Display the Hardware Settings
dialog box with device information and side tabs to
change the device name, internal clock, and password of
connected device.
It also contains an Edit Communication Settings
button, which provides an alternative method of accessing
the Communication Settings dialog box.
•
Communication Settings — Open the Communication
Settings dialog box to change IP settings of the
connected device.
• Reset Device — Open the Reset Device dialog box, with selectable models for resetting the connected
device, as well as the Unit Information (also displayed in the Hardware Settings dialog box).
•
Update Firmware — Open a submenu to upload firmware from the host device to the connected device or to
multiple devices.
NOTE: If necessary, download a new firmware from the Extron website (see
Installation
• Update Firmware to this Device... — Upload firmware from the host device to the connected
device only.
•
Update Firmware to Multiple Devices... — Upload firmware to multiple devices on the network.
NOTE: The connected devices must be connected via LAN.
• DTP3 T 101 D Help — Open the DTP3 T 101 D Help File in a separate window.
•
About this Module — Open the About This Module dialog box, with the module part number and firmware
version of the connected device.
on page 16).
Figure 21.
DTP3 T 101 D • Proudct Configuration Sotware
Device Menu
