Operation

This section describes the operation of the DTP2 T 203 switcher. Topics include:
•
•
•

Front Panel Features

Figure 9.
A
B
C
D
E
F
Front Panel Features
Operation
Configuration
A B C D
AUTO
SWITCH
R
CONFIG
e
MODE
DTP2 T 203 Front Panel
Auto Switch LED — Lights when auto‑input switching is enabled.
A B C C
Reset button — To initiate factory default reset, use a pointed object, such as a small
POWER
INPUTS
Phillips screwdriver or stylus, to press and hold the button for 5 seconds while the
12V
1 2
AUDIO
1.5A MAX
switcher is running or while it is being powered up.
HDMI HDMI
NOTE: The switcher can also be reset to its factory default settings using SIS
commands (see Reset
Configuration port — Connect a USB cable (USB A to mini‑B) to a computer and this
female USB mini‑B port to configure the device and update the firmware via PCS or SIS
commands (see Connecting to the USB Port
Input selection buttons and LEDs — Press one of these buttons to select an input to
switch to the output. The LED at the right of each button lights when the corresponding
input is selected. If auto‑input switching is in effect, these buttons are disabled, but the
LEDs continue to light to indicate the selected input.
NOTE: The input buttons are also used to enable and disable auto‑input switching
(see Enabling Auto-Input Switching
switching can also be configured using SIS commands (see
on page 48).
Signal Status LEDs — Lights when a source is connected to the input port.
HDCP Status LEDs — Lights if the currently selected input requires HDCP and the
connected output device has been successfully authenticated.
D D
1 2 3
NORMAL AUTO
C D E F
SIG LINK
SEND
HDBT OVER TP
POWER
3
RS-232
DP
OUT Tx
OFF DTP
on page 54) or PCS (see
on page 19).
on page 19 for details). Auto‑input
E
STATUS
1 2 3
SIGNAL
HDCP
DTP2 T 203
F
G H I
REMOTE
IR CONTACT IN TALLY OUT RS-232
Rx G Tx Rx 1 2 3 G 1 2 3 + V Tx Rx G
Reset Device on page 39).
Auto-switch mode
DTP2 T 203 • Operation
LAN
17
