• DTP mode — If the receiving device is in the Extron DTP3 series, set this switch to the down (DTP)
position.If the transmitter and receiver are in the Extron DTP3 series, they can both be powered by one
12 VDC power supply connected to either unit.
NOTE: If the transmitter and receiver are NOT both in the Extron DTP3 series, the transmitter and
receiver each require its own 12 VDC power supply.
• HDBaseT mode — If the receiving device is HDBaseT enabled receiver, set this switch to the up (HDBT)
position. The TP output transmits HDMI digital video with embedded audio up to 330 feet (100 meters) to
any device with an HDBaseT input. The transmitter and receiver each require its own 12 VDC power
supply.
Send Power toggle switch (see
F
configuration, set the toggle switch to the up (SEND POWER) position on the powered DTP3 unit to enable
sending remote power to the far end. Set the toggle switch to the down (OFF)position on the DTP3 unit
receiving power.
ATTENTION:
•
The DTP3 T 101 D is configured to output power to DTP3 models only. If connected to a non‑
DTP3 device, set the SEND POWER toggle switch to the down (OFF) position. Failure to turn the
power off will damage the connected non‑DTP3 device (see
•
Le DTP3 T 101 D est configuré pour fournir une alimentation aux modèles DTP3 uniquement. S'il
est connecté à un autre appareil, veuillez positionner l'interrupteur à bascule sur « down » (OFF).
Si l'interrupteur n'est pas positionné sur Off, vous risquez d'entraîner la défaillance de l'appareil
non DTP3 connecté (voir
NOTES:
•
When the output is configured for DTP mode, remote power is available only if both the transmitter
and the receiver are from the DTP3 series.
•
When the output is configured for HDBT mode, remote power is not available and both the
transmitter and receiver require their own 12 VDC power supply.
TP output — Connect one end of the twisted pair cable to the RJ‑45 port on the transmitter (see
G
Termination/Recommendation for DTP Communication
Connect the opposite end of the cable to a DTP3 or HDBaseT compatible receiving device. This port has two
LEDS:
•
Signal LED — Lights green when the transmitter outputs a video signal.
• Link LED — Lights yellow when DTP devices are connected and communication is established.
ATTENTION:
•
Do not connect these outputs to a telecommunications or computer data network.
• Ne connectez pas ces appareils à des données informatiques ou à un réseau de
télécommunications.
figure 4 on page 7) — In a DTP3 transmitter to DTP3 receiver
figure 5 la page 9).
figure 5 on page 9).
on page 10 to properly wire the RJ‑45 connector).
