5.6.15.1 Selecting parameters (program A)

Operating
element
m/min
m/min
Changes to the welding parameters can only be made when the key switch is in position
"1".

5.6.16 MIG/MAG automatic cut-out

The welding machine ends the ignition process or the welding process with an
• ignition fault (no welding current flows within 5 s after the start signal)
• arc interruption (arc is intrerupted for longer than 5 s)
099-005023-EW501
09.08.2010
Action Result
Change welding data display over to program
display.
n x
(LED PROG is on)
Select program number.
Display example: Program "1".
Select program sequence parameter
"Main program (P
n x
(LED is on)
Set wire speed.
(Absolute value)
Set arc length correction.
Display example: "-0.8 V" correction
(Setting range: -9.9 V to +9.9 V)
Select "Dynamic" program sequence parameter.
1 x (LED DYN
Set dynamic. (Setting range 40 to -40)
40: Arc hard and narrow.
-40: Arc soft and wide.
)".
A
is on)
