Design and function
MIG/MAG welding

5.6.21 Advanced settings

The special parameters cannot be viewed directly since they are normally only set and stored once. The
machine control offers the following special functions:

5.6.21.1 Selecting, changing and saving parameters

0
1
ENTER (Enter the menu)
• Switch off machine at the main switch.
• Press and hold the "left parameter selection" button and switch the machine on again at the
same time.
NAVIGATION (Navigate in the menu)
• Parameters are selected by turning the "welding parameter setting" rotary dial.
• Set or change the parameters by turning the "arc length correction/select welding program"
rotary dial.
EXIT (Exit the menu)
• Press the "right parameter selection" button (settings will be applied, machine changes to
the ready-to-operate status).
66
A M P 0
1
HOLD
m /m in
Figure 5-37
NOTE
VOLT
PROG
m /m in
