5.8.5

Hotstart

The hotstart device improves the ignition of the stick electrodes using an increased ignition current.
a) = Hotstart time
b) = Hotstart current
I = Welding current
t = Time
For hotstart parameter settings, see "parameter overview" chapter
5.8.6

Antistick

5.8.7

Parameter overview

Basic parameters
Item Meaning/explanation
1 Welding current
2 Hotstart time
3 Hotstart current
4 Arcforce
The hotstart current is a percentage based on the welding current selected.
099-005023-EW501
09.08.2010
3 4
sec
2
sec
1
sec
Super-
puls
Figure 5-50
Anti-stick prevents the electrode from annealing.
If the electrode sticks in spite of the Arcforce device, the
machine automatically switches over to the minimum
current within about 1 second to prevent the electrode
from overheating. Check the welding current setting
and correct according to the welding task!
DYN
sec
sec
sec
Figure 5-51
Setting range
5 A to maximum welding current
0 to 20 s
0 to 200 %
-40 to 40
NOTE
Design and function
MMA welding
sec sec
