Machine description – quick overview
Machine control – Operating elements
4.3.1 Machine control – Concealed operating elements
M 3.71
16
17
Item Symbol Description
1
2
3
sec
4
5 sec
6
7
DYN
8 sec
9
10 sec
11 sec
12
13 sec
14
22
4 3
Material
sec
Gas
Wire
8
JOB-
LIST
sec
Super-
puls
2
15
0
Select welding parameters button
This button is used to select the welding parameters depending on the welding process
and operating mode used.
Signal light, gas pre-flow time
Setting range 0.0 s to 20.0 s
Signal light, start program (P
• Wire speed:1% to 200% of the main program P
• Correction of the arc length -9.9 V to +9.9 V
Signal light, start time
Setting range, absolute 0.0 s to 20.0 s (0.1 s increments)
Signal light, slope time program P
Setting range 0.0 s to 20.0 s (0.1 s increments)
Signal light, main program (P
• Wire speed WF-min. to WF-max.
• Correction of the arc length -9.9 V to +9.9 V
Signal light, dynamics
Setting range -40 to +40
Signal light, duration of main program P
Setting range 0.0 s to 20.0 s (0.1 s increments).
Used e.g. in connection with the super pulse function
Signal light, reduced main program (P
• Wire speed:1% to 200% of the main program P
• Correction of the arc length -9.9 V to +9.9 V
Signal light, duration reduced main program P
Setting range 0.0 s to 20.0 s (0.1 s increments).
Used e.g. in connection with the super pulse function.
Signal light, slope time program P
Setting range 0.0 s to 20.0 s (0.1 s increments)
Signal light, end program (P
• Wire speed:1% to 200% of the main program P
• Correction of the arc length -9.9 V to +9.9 V
Signal light, duration of end program P
Setting range 0.0 s to 20.0 s (0.1 s increments)
Signal light, gas post-flow time
Setting range 0.0 s to 20.0 s
5 7 6 10 9
DYN
sec
sec
sec
sec
sec
13
1
Figure 4-4
)
START
to main program P
START
)
A
A
)
B
(or P ) to end program P
A B
)
END
END
11 12
sec
14
A
A
A
B
END
A
