EWM Phoenix 301 Progress puls Operating Instructions Manual page 17

Item Symbol Description
1
2
3
4
5
6
7
8
9
10
11
12
13
099-005023-EW501
09.08.2010
Machine description – quick overview
0
Lifting lug
Carrying handle
Machine control
See Machine control – operating elements chapter
Main switch, machine on/off
19-pole connection socket (analogue)
For connecting analogue accessory components (remote control, welding torch control
lead, etc.)
7-pole connection socket (digital)
For connecting digital accessory components (remote control, welding torch control
lead, etc.)
Central connection for welding torch (Euro)
Integrated welding current, shielding gas and torch trigger
Welding current cable, polarity selection
Welding current to the central connector/torch, enables polarity selection.
• MIG/MAG: Connection socket for "+" welding current
• Self-shielding cored wire/TIG: Connection socket for "-" welding current
Connection socket, "+" welding current
• MIG/MAG cored wire welding:
• TIG welding:
• MMA welding:
"-" welding current connection socket
• MIG/MAG welding:
• TIG welding:
• MMA welding:
Cooling air inlet
Conveyor rolls, guide castors
Conveyor rolls, fixed castors
Workpiece connection
Workpiece connection
Workpiece connection
Workpiece connection
Welding current connection for welding torch
electrode holder connection
Front view
17
