Design and function
MIG/MAG welding
"Single or dual operation" (P10) setting
If the system is fitted with two wire feeds, no further accessory components may be
operated on the 7-pole connection socket (digital)!
This relates to digital remote controls, robot interfaces, documentation interfaces, welding
torches with digital control lead connection, etc.
No second wire feed may be connected in single operation (P10 = 0)!
• Remove connections to the second wire feed
In dual operation (P10 = 1 or 2), both wire feed units must be connected and configured differently
on the controls for this operating mode!
• Configure one wire feed unit as the master (P10 = 1)
• Configure the other wire feed unit as a slave (P10 = 2)
Wire feed units with key switches (optional, see Key switches chapter) must be configured as
masters (P10 = 1).
The wire feed configured as the master is active after the welding machine is switched on. There
are no other functional differences between the wire feeds.
Latched special tapping time setting (P11)
The tapping time for changing over between the main program and reduced main program can be set in
three levels.
0 = no tapping
1 = 320ms (factory setting)
2 = 640ms
JOB list switching (P12)
Value Designation
0 Task-oriented
JOB list
1 Actual JOB list
2 Actual JOB list,
JOB changeover active
74
NOTE
Explanation
The JOB numbers are sorted by welding wires and shielding gases.
JOB numbers may be skipped during selection where relevant.
JOB numbers correspond to the actual memory cells. Each JOB can be
selected; no memory cells are skipped during selection.
As for the actual JOB list. JOB changeover is also possible with
accessory components, such as the PowerControl 2 torch.
