IQH3-FP-V1

Product Description

3
Product Description
3.1
Product Description
Use and Application
The IQH3-FP-V1 read/write device is designed for writing and reading passive tags in the 13.56
MHz frequency range in accordance with the ISO15693 standard. The read/write device must
be operated with an IDENTControl control interface from Pepperl+Fuchs.
Figure 3.1
3.2

Dimensions

Figure 3.2
10
IQH3-FP-V1
80
65
IQH3-FP-V1
40
LED (4x)
7
