- Page 1 Manual IDM161-M-1D-J1-BT-N-N0 IDM261-M-2D-J1-BT-N-N0 Bluetooth handheld scanner for use in explosion- hazardous areas Zone 1/21...
- Page 3 The latest version of the General Terms of Supply for Products and Services in the Electronics Industry set out by the German Electrical and Electronic Manufacturers’ Association (ZVEI) and the "Extended Reservation of Proprietorship" supplementary clause apply to this document.
-
Page 4: Table Of Contents
T able of onTenTs Table of Contents 1. Important Notes About The Instruction Manual ........6 1.1. Safety Information ..................6 1.2. Notes About The Manual ................7 1.3. General Warning Messages ................9 2. Technical Data ..................12 2.1. Explosion Protection ..................12 2.2. -
Page 6: Important Notes About The Instruction Manual
I mporTanT oTes bouT nsTruCTIon anual 1. Important Notes About The Instruction Manual 1.1. Safety Information This document contains symbols to identify warning messages and information mes- sages. Warning messages You always find warning messages whenever hazards could result from your actions. It is essential that you observe these warning messages to ensure your personal safe- ty and to prevent property damage. -
Page 7: Notes About The Manual
Observe the information given in this manual during commissioning and use of the product. There is no responsibility for actuality. Pepperl+Fuchs GmbH reserves the right to make changes to this document. Prior to use, make sure that you have the latest version of the user manual. Check the homepage www.pepperl-fuchs.com or contact your contact person at Pepperl+Fuchs... - Page 8 DANger! Do not make any changes to the device that are not intended or been approved by Pepperl+Fuchs. Improper handling of the handheld scanner can void the type approval to operate in explosion-hazardous areas. Non-compliance excludes warranty claims.
-
Page 9: General Warning Messages
I mporTanT oTes bouT nsTruCTIon anual 1.3. general Warning Messages WArNINg! Only operate the devices when assembled. Do not clean the device in explosion-hazardous areas. Do not wipe it dry. Switch off the device immediately if you believe that the device can no longer be operated safely after damaging effects or abnormalities in general (ingress of water, fluids, exposure to temperatures outside the specified range etc.). - Page 10 I mporTanT oTes bouT nsTruCTIon anual WArNINg! Devices equipped with lasers comply with the standards US 21 CFR 1040.10 and EN 60825-1. The classification of the laser device is specified on a plate attached to the device. Class 1 laser devices are not considered to be hazardous under the intended use.
-
Page 11: Technical Data
II 2G Ex ib IIB T4 Gb II 2D Ex ib IIIC T135°C II 2D Ex ib IIIC T135°C Db Test certificate IBExU18ATEX1050 IECEx IBE 18.0009 Manufacturer Pepperl+Fuchs GmbH Lilienthalstraße 200 68307 Mannheim, Germany info@de.pepperl-fuchs.com 2.2. Technical Data for Bluetooth Scanner IDM161-M-1D-J1-BT- IDM161-M-1D-J1-BT-... -
Page 12: Use
T T eChnICal eChnICal IDM161-M-1D-J1-BT- IDM161-M-1D-J1-BT- IDM261-M-2D-J1-BT- N-N0 P-N0 N-N0 Scan frequency 500 Hz 60 Hz Reading dis- 20 mm ... 850 mm 30 mm ... 160 mm tance Code resolution Approx. ≥ 0.076 mm Approx. ≥ 0.13 mm Immunity to 100,000 lx extraneous... - Page 13 s s ysTem TruCTure ysTem TruCTure 3. S yStem tructure 3.1. Overview The Bluetooth handheld scanners and their accessories are presented in the fol- lowing overview. Charging the handheld scanner batteries can take place within the hazardous area using the zone 1/21 certified base station/charging cradle and the associated power module.
-
Page 14: System Structure
s s ysTem TruCTure ysTem TruCTure 3.2. System Structure 1 Overview of the complete system structure 1: Bluetooth handheld scanners IDM161- M1D-J1-BT-N-N0, IDM261-M-2D-J1-BT-N-N0, and base station connected to intrinsi- cally safe RS232 Ex i interface VisuNet GXP. RM-/PC-GXP1100*3* RS232 Ex i interface option „3“... -
Page 15: System Structure 1
s ysTem TruCTure 3.3. System Structure 2 Overview of the complete system structure 2: Bluetooth handheld scanners IDM161- M1D-J1-BT-N-N0, IDM261-M-2D-J1-BT-N-N0, and base station and power module in explosion-hazardous areas. Host PC AC/DC Power supply 24 V DC Data (in case of option 2) USB / RS232 RM-/PC-GXP1100*2* IDMx61-M*... -
Page 16: System Structure 2
s ysTem TruCTure 3.4. System Structure 3 Overview of the complete system structure 3: Bluetooth handheld scanner and charging cradle in non-explosion-hazardous areas PSU-IDMx61-BC-N0-N0 Non-Ex AC/DC IDMx61-B-N0-BT-N0 Power supply (IDMx61-C-N0-BT-N0) Non-Ex Base Station Or Charger Host PC CBL-IDMx61-B-N0* Non-Ex Data cable RS232 / USB Data (in case of option 2) USB / RS232... -
Page 17: Commissioning
C C ommIssIonIng ommIssIonIng 4. Commissioning 4.1. Preparing Bluetooth Handheld Scanners DANger! The battery must not be changed or inserted in explosion-hazardous areas. Improper handling can void the type approval. Preparation of Bluetooth handheld scanners The battery compartment is located on the underside of the Bluetooth handheld scanner. - Page 18 C C ommIssIonIng ommIssIonIng DANger! The designated battery may only be used! The battery is inserted into the compartment on the handheld scanner. The end of the pull tab must be seen protruding out of the opening of the handheld scanner. If the battery is inserted correctly and connected to the contacts, there is an audible and visual signal.
- Page 19 C ommIssIonIng The plug of the cordset is connected to the power module plug coupling. Ensure that the connection is fully secured to the screw cap after plugging together. Figure 9. Connecting the plug coupling to the power module basic connection line The handheld scanner is placed in the charger.
- Page 20 C ommIssIonIng Using the base station in non-explosion hazardous areas - sys- tem structure 2 With a non-explosion-protected base station, charging in non-explosion hazardous areas can be performed using the PSU-IDMx61-BC-N0-N0 power supply. The ca- ble is plugged into the opening for this at the bottom of the base station. For a base station for explosion-hazardous areas, this connection is sealed at the factory.
-
Page 21: Pinout Of Power Module With Rs232
C ommIssIonIng The handheld scanner is placed in the charger. The underside of the handle is used first to ensure that the charging contacts are properly connected. The LED light on the scanner head indicates successful charging. Figure 13. Inserting the scanner into the base station 4.2. - Page 22 C ommIssIonIng Figure 14. Power module terminal compartment Base connection line rS232 The blue base connection cable is delivered pre-assembled with the power module PSU-IDM*. The cable consists of a M12 connector plug and a 3-core cable. The individual cores are numbered (printed on the core insulation) and must be connec- ted as follows to the intrinsically safe terminals of the power module.
- Page 23 C ommIssIonIng Direct connection of the base station without a plug/coupling to the power module with rS232 interface The base station can be connected directly to the power module without using the blue connection cable. The assignment of the serial base station cable is outlined in the following table. Figure 14.
-
Page 24: Pinout Of Power Module With Usb
C ommIssIonIng 4.3. Pinout of power module with USB Supplying the base station according to system structure 2 via connector - plug/coupling. The terminal assignment is located under the unscrewable opening on the front of the power module. DANger! Do not open the housing in the explosion-hazardous area Before the device is put into operation in explosion-hazardous areas, it must be ensured that the housing is completely closed again and screwed on properly. - Page 25 C ommIssIonIng Figure 18. Terminal blocks in the terminal compartment The blue base connection cable is delivered pre-assembled with the power module PSU-IDM*. The cable consists of a M12 connector plug and a 4-core cable. The individual cores are numbered (printed on the core insulation) and must be connec- ted as follows to the intrinsically safe terminals of the power module.
- Page 26 C ommIssIonIng Direct connection of the base station without plug/coupling to the power module with USB interface Figure 19. RJ45 plug - connection layout Base station cordset Power module terminal compart- Cordset assignment ment rJ45 pinout Strand color Designation Assignment Green D+2SL...
-
Page 27: Accessories
Supports PDF417 barcode IDM260-D-2D-J1-S1-N-N0 Wired handheld scanner for 2-D codes ATEX & IECEx Zone 1/21 Wireless handheld barcode scanner IDM161-M-1D-J1-BT-N-N0 Bluetooth handheld scanner for 1-D codes ATEX & IECEx Zone 1/21 IDM161-M-1D-J1-BT-P-N0 Bluetooth handheld scanner for 1-D codes ATEX & IECEx Zone 1/21... - Page 28 a CCessorIes Designation Description PSU-IDM260-D-2D-J1-DC- Power module for wired 2-D handheld scanner S-N0 ATEX & IECEx Zone 1/21 RS232 connection, 24 VDC For IDM260-D-2D-J1* PSU-IDM260-D-2D-J1-AC- Power module for wired 2-D handheld scanner S-N0 ATEX & IECEx Zone 1/21 RS232 connection, 230 VAC For IDM260-D-2D-J1* PSU-IDMx61-BC-N0-N0 Power supply for non-explosion-hazardous base station &...
- Page 29 a CCessorIes Designation Description CBL-IDMx61-B-J1-S-C38-N0 RS232 connection cable base station ATEX & IECEx Zone 1/21 3.8 m length, spiral For IDMx61-B-J1* CBL-IDMx61-B-J1-U-S18-N0 USB connection cable base station ATEX & IECEx Zone 1/21 1.8 m length, smooth For IDMx61-B-J1* CBL-IDMx61-B-J1-U-C38-N0 USB connection cable base station ATEX &...
- Page 30 Pepperl+Fuchs Quality Download our latest policy here: www.pepperl-fuchs.com/quality www.pepperl-fuchs.com www.pepperl-fuchs.com www.pepperl-fuchs.com Subject to modifications · © Pepperl+Fuchs Subject to modifications Subject to modifications © Pepperl+Fuchs © Pepperl+Fuchs · · Printed in Germany · 2018-07 · DOCT-6088 Printed in Germany Printed in Germany Part.
