  • Page 1 IDM-Z2-160-D-1D-J2-SU-N-N0 IDM-Z2-160-D-1D-J2-SU-P-N0 IDM-Z2-260-D-2D-J2-S1-N-N0 Wired handheld scanner for use in explosion-hazardous areas Zone 2/22 Manual...
  • Page 2 Phone: +49 621 776 - 0 E-mail: info@de.pepperl-fuchs.com North American Headquarters Pepperl+Fuchs Inc. 1600 Enterprise Parkway Twinsburg, Ohio 44087 Phone: +1 330 425-3555 E-mail: sales@us.pepperl-fuchs.com Asia Headquarters Pepperl+Fuchs Pte. Ltd. P+F Building 18 Ayer Rajah Crescent Singapore 139942 Phone: +65 6779-9091 E-mail: sales@sg.pepperl-fuchs.com https://www.pepperl-fuchs.com...

  • Page 3: Table Of Contents

    IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 History of the Manual ....................4 Introduction........................ 5 Content of this Document ................5 Manufacturer ....................5 Target Group, Personnel ................5 Symbols Used ....................5 Technical Specifications ................... 7 Explosion Protection ..................7 Technical Data for Corded Reader ............... 8 Use ........................

  • Page 4: History Of The Manual

    IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 History of the Manual The following editions of the manual have been released: Version Comments 01/2022 First edition...

  • Page 5: Introduction

    IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Introduction Content of this Document This document contains information required to use the product in the relevant phases of the product life cycle. This may include information on the following: • Product identification • Delivery, transport, and storage •...
  • Page 6 IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Warning Messages You will find warning messages, whenever dangers may arise from your actions. It is mandatory that you observe these warning messages for your personal safety and in order to avoid prop- erty damage. Depending on the risk level, the warning messages are displayed in descending order as fol-...

  • Page 7: Technical Specifications

    IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Technical Specifications Explosion Protection IDM-Z2-160-D-1D-J2-* II 3G Ex ic IIC T4 Gc II 3D Ex ic IIIC T135°C Dc IDM-Z2-260-D-2D-J2-* II 3G Ex ic IIB T4 Gc II 3D Ex ic IIIC T135 °C DC Test certificate IBExU19ATEXB016X IECEx IBE 19.0026X...

  • Page 8: Technical Data For Corded Reader

    IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 68307 Mannheim Germany info@de.pepperl-fuchs.com Technical Data for Corded Reader IDM-Z2-160-D-1D- IDM-Z2-160-D-1D- IDM-Z2-260-D-2D- J2-SU-N-N0 J2-SU-P-N0 J2-S1-N-N0 Description Linear imager 2-D imager Barcode One-dimensional 1-D One-dimensional 1-D One-dimensional 1-D (barcode) (Barcode and stack & 2-D code incl. PDF417) (Barcode and stack code incl.

  • Page 9: Use

    IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 The handheld reader is a piece of handheld device. It enables portable recording and direct data transfer in explosion-hazardous areas. The device is modified for use in explosion-hazardous areas of Zone 2 and Zone 22.

  • Page 10: System Structure

    IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 System Structure Overview The wired handheld readers and their accessories are presented in the following overview. The handheld readers can be used in stand-alone applications or can be connected to a Pep- perl+Fuchs VisuNet operator workstation. Connections to the VisuNet FLX are realized with an additional barrier (SK-IDM-Z2-J2-1M-U-N) or via an integrated barrier when connecting the barcode reader to the VisuNet GXP.
  • Page 11 IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0...

  • Page 12: Idm-Z2-X60-D-* System Structure 1

    IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Figure 4.1 Warning! Wired handheld readers may only be operated with the specified Pepperl+Fuchs connection cables! Handheld readers may only be operated on the specified Pepperl+Fuchs supply modules/bar- riers! The warning messages in this instruction manual and the SICK AG manual (www.SICK.com) must be observed! In the following two subchapters, the typical usage cases are described in more detail.

  • Page 13: Idm-Z2-X60-D-* System Structure 2

    IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Description: The handheld barcode reader is designed to be used in explosion-hazardous areas Zone 2/22. For proper operation in explosion-hazardous areas, the permissible RS-232 cordsets CBL- IDMx60-D-J1-S* must be used. The intrinsically safe power supply and data transfer are real- ized via this cable.

  • Page 14: Idm-Z2-X60-D-* System Structure 3

    IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Item Num- Product Name Description Photo #70142693 HOLDER-BRACKET- Bracket to wall-mount SK-IDM-Z2-J2-* SK-IDM-Z2-N0 barrier - Material: Stainless steel AISI 304 (1.4301) - NOTE: Barrier not included! #70142118 GR.TJE.13.13.09.B- Enclosure material: glass fiber reinforced S0008 polyester (GRP)
  • Page 15 IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Zone 2/22 Barcode Reader, USB connection to VisuNet FLX: Figure 4.4...

  • Page 16: Idm-Z2-160-D-J2-Su-* System Structure 4

    IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Required Components: • VisuNet FLX System configured with adapter ADAPTER-3200-10-304B-M12 • Corded barcode reader • Connection cable • Supply cable (USB) • SCANNER-HOLDER-U1-3200-N0 Description: The handheld reader is designed to be used in explosion-hazardous areas. For proper opera- tion in explosion-hazardous areas, the permissible USB supply cable SK-IDM-Z2-J2-1M-U-N cordsets must be used.

  • Page 17: Idm-Z2-160-D-J2-Su-* System Structure 5

    Note The installation of the IDM-Z2-160-D-1D-J2-SU-N-N0 and IDM-Z2-160-D-1D-J2-SU-P-N0 barcode reader to the integrated barrier of the VisuNet GXP requires the optional interface "3". Refer to the VisuNet GXP technical data (Module A and B) for further information regarding the interfaces.
  • Page 18 IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Description: The handheld reader is designed to be used in explosion-hazardous areas. For proper opera- tion in explosion-hazardous areas, the permissible RS-232 cordsets CBL-IDMx60-D-J1-S* must be used. The intrinsically safe power supply and data transfer are realized via this cable.

  • Page 19: Commissioning

    IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Commissioning Connection of the Wired Handheld Readers Connection of wired handheld readers Connect the RJ50 plug on the connection cable CBL-IDMx60* for connecting the handheld reader to the power module at the bottom of the scanner. Make sure that they are properly con- nected.

  • Page 20: Pin Allocation Of Supply Cable Sk-Idm-Z2-J2-5M-S-N Rs-232 Interface

    IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Pin allocation of supply cable SK-IDM-Z2-J2-5M-S-N RS-232 inter- face Supply of the corded barcode reader Zone 2/22 according to system configuration 1 and 2 via plug-in connection plug/coupler. Figure 5.3 Note The serial connection cables come with a yellow marking.
  • Page 21 IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Supply and data transmission with RS-232 interface to a host PC outside the hazard- ous area Supply cable Designation 9-pole Sub-D RS-232 Pin TXD / RS-232 (white) GND / RS-232 (brown) TxD+ / RS-422 (yellow) TxD- / RS-422 (green)

  • Page 22: Pin Allocation Of Supply Cable Sk-Idm-Z2-J2-1M-U-N Usb Interface

    IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Pin allocation of supply cable SK-IDM-Z2-J2-1M-U-N USB interface Supply of the corded Zone 2/22 barcode reader according to system configuration 3 via plug-in connection plug/coupler. Figure 5.4 Note The USB connection cables come with a green marking.
  • Page 23 IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Supply and data transmission with a USB interface to a host PC outside the hazardous area Supply cable Pins Designation USB Pin 1 (red) 2 (white) 3 (green) 5 (black) Note Information relating to programming from the SICK AG manual (www.SICK.com) is required for...

  • Page 24: Accessories

    IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Accessories Corded handheld reader mounting accessories Item num- Product name Description Photo #548267 SCANNER-HOLDER- Reader holder compatible with Housing U1-XX00-N0 AG-XX00 Material: Stainless steel AISI 304 (1,4301) Compatible with IDMx6x, ecom Ident- Ex® 01 and PSCAN...
  • Page 25 IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Corded handheld reader accessories for VisuNet HMI Applications Suitable for Zone 1/21 & Zone 2/22 Item num- Cable Product name Description Photo #548333 CBL-IDMx60-D-J1-S- Connection cable for Straight 1.8-m S18-N0 corded code readers length Interface: RJ50...
  • Page 26 IDM-Z2-160-D-1D-J2-SU-N-N0, IDM-Z2-160-D-1D-J2-SU-P-N0, IDM-Z2-260-D-2D-J2-S1- N-N0 Supply cables Explosion protection: ATEX & IECEx Zone 2/22 Item num- Product name Description Photo #70142704 SK-IDM-Z2-J2-1M-U- Cable-Barrier for corded 1-D & 2-D reader & base station Explosion protection: ATEX & IECEx Zone 2/22 Protocol: USB (via USB Type A connec-...
  • Page 27 Pepperl+Fuchs Quality Download our latest policy here: www.pepperl-fuchs.com/quality www.pepperl-fuchs.com © Pepperl+Fuchs · Subject to modifications Printed in Germany / DOCT-8043...
